Wiring diagram: Instrument cluster — Clock circuit Kia Rio III
All systems — 31 systems
- Air conditioning 2
- Anti-lock brakes
- Anti-theft 5
- Body control modules
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers 2
- Electronic power steering
- Engine performance 1.6l 3
- Exterior lights 3
- Ground distribution
- Headlights 4
- Horn
- Instrument cluster 5
- Interior lights 2
- Navigation
- Power distribution
- Power door locks
- Power mirrors 4
- Power seats 3
- Power top/sunroof
- Power windows 4
- Radio 6
- Shift interlock
- Starting/charging 9
- Supplemental restraints
- Transmission
- Trunk, tailgate, fuel door 2
- Warning systems 2
- Wiper/washer 5
Components on these wiring diagrams 10
Click a component to highlight it on every diagram it appears on.
