Starter [Non-ISG type]
| Item | Specification | |
|---|---|---|
| Rated voltage | 12 V, 0.9 kW | |
| The number of pinion teeth | 10 | |
| Performance [No-load, 11.5 V] | Ampere | Max. 60 A |
| Speed | Min. 5, 500 rpm | |
Starter [ISG type]
| Item | Specification | |
|---|---|---|
| Rated voltage | 12 V, 1.3 kW | |
| The number of pinion teeth | 11 | |
| Performance [No-load, 12 V] | Ampere | Max. 95 A |
| Speed | Min. 3400 rpm | |
Scheme 29
Scheme 30
Scheme 31
Scheme 32
- Disconnect the battery negative terminal.
- Remove the air duct and air cleaner assembly. (Refer to «REMOVAL AND INSTALLATION»(ref-536078-S08913351222013031400000) .
- Disconnect the starter cable (B) from the B terminal on the solenoid then disconnect the connector from the S terminal (A).
- Remove the 2 bolts holding the starter, then remove the starter (A).
Cleaning
- Do not immerse parts in cleaning solvent. Immersing the yoke assembly and/or armature will damage the insulation. Wipe these parts with a cloth only.
- Do not immerse the drive unit in cleaning solvent. The overrun clutch is pre-lubricated at the factory and solvent will wash lubrication from the clutch.
- The drive unit may be cleaned with a brush moistened with cleaning solvent and wiped dry with a cloth.
