3. OBD-II SYSTEM READINESS TESTS
- CATALYST MONITORING The catalyst efficiency monitor is a self-test strategy within the ECM/PCM that uses the downstream Heated Oxygen Sensor (HO2S) to determine when a catalyst has fallen below the minimum level of effectiveness in its ability to control exhaust emission.
- MISFIRE MONITORING Misfire is defined as the lack of proper combustion in the cylinder due to the absence of spark, poor fuel metering, or poor compression. Any combustion that does not occur within the cylinder at the proper time is also a misfire. The misfire detection monitor detects fuel, ignition or mechanically induced misfires. The intent is to protect the catalyst from permanent damage and to alert the customer of an emission failure or an inspection maintenance failure by illuminating the MIL. When a misfire is detected, special software called freeze frame data is enabled. The freeze frame data captures the operational state of the vehicle when a fault is detected from misfire detection monitor strategy.
- FUEL SYSTEM MONITORING The fuel system monitor is a self-test strategy within the ECM/PCM that monitors the adaptive fuel table The fuel control system uses the adaptive fuel table to compensate for normal variability of the fuel system components caused by wear or aging. During normal vehicle operation, if the fuel system appears biased lean or rich, the adaptive value table will shift the fuel delivery calculations to remove bias.
- ENGINE COOLING SYSTEM MONITORING The cooling system monitoring is a self-test strategy within the ECM/PCM that monitors ECTS (Engine Coolant Temperature Sensor) and thermostat about circuit continuity, output range, rationality faults.
- O2 SENSOR MONITORING OBD-II regulations require monitoring of the upstream Heated O2 Sensor (H2OS) to detect if the deterioration of the sensor has exceeded thresholds. An additional HO2S is located downstream of the Warm-Up Three Way Catalytic Converter (WU-TWC) to determine the efficiency of the catalyst. Although the downstream H2OS is similar to the type used for fuel control, it functions differently. The downstream HO2S is monitored to determine if a voltage is generated. That voltage is compared to a calibrated acceptable range.
- EVAPORATIVE EMISSION SYSTEM MONITORING The EVAP. monitoring is a self-test strategy within the ECM/PCM that tests the integrity of the EVAP. system. The complete evaporative system detects a leak or leaks that cumulatively are greater than or equal to a leak caused by a 0.040 inch and 0.020 inch diameter orifice.
- AIR CONDITIONING SYSTEM MONITORING The A/C system monitoring is a self-test strategy within the ECM/PCM that monitors malfunction of all A/C system component at A/C ON.
- COMPREHENSIVE COMPONENTS MONITORING The comprehensive components monitoring is a self-test strategy within the ECM/PCM that detects fault of any electronic powertrain components or system that provides input to the ECM/PCM and is not exclusively an input to any other OBD-II monitor.
Scheme 21
Scheme 22
Scheme 23
Scheme 24
Scheme 25
Scheme 26
2. PCM TERMINAL FUNCTION (A/T)
CONNECTOR [C01-1]
| Pin | Description | Connected to |
|---|---|---|
| 1 | Ground | Chassis Ground |
| 2 | Ground | Chassis Ground |
| 3 | Ground | Chassis Ground |
| 4 | For Autotransaxle Control | |
| 5 | For Autotransaxle Control | |
| 6 | Batter voltage supply after main relay | Main Relay |
| 7 | ||
| 8 | Sensor ground | MAFS & IATS |
| 9 | Sensor ground | Heated Oxygen Sensor (HO2S) [Bank 1 / Sensor 2] |
| 10 | Mass Air Flow Sensor (MAFS) signal input | Mass Air Flow Sensor (MAFS) |
| 11 | ||
| 12 | ||
| 13 | Heated Oxygen Sensor (HO2S) [Bank 1 / Sensor 2] signal input | Heated Oxygen Sensor (HO2S) [Bank 1 / Sensor 2] |
| 14 | ||
| 15 | ||
| 16 | ||
| 17 | Load signal input (Defrost) | Defrost Relay |
| 18 | ||
| 19 | ||
| 20 | Vehicle speed signal input | ABS Control Module [with ABS] |
| 21 | ||
| 22 | Load signal input (Head Lamp) | Multi Function Switch |
| 23 | A/C switch signal input | A/C Control Module |
| 24 | Ground (For Autotransaxle) | Chassis Ground |
| 25 | Ground (For Autotransaxle) | Chassis Ground |
| 26 | For Autotransaxle Control | |
| 27 | For Autotransaxle Control | |
| 28 | ||
| 29 | Sensor ground | Fuel Tank Pressure Sensor (FTPS) |
| 30 | Ground | A/C Pressure Transducer |
| 31 | Sensor ground | Heated Oxygen Sensor (HO2S) [Bank 1 / Sensor 1] |
| 32 | Intake Air Temperature Sensor (IATS) signal input | Intake Air Temperature Sensor (IATS) |
| 33 | ||
| 34 | ||
| 35 | Heated Oxygen Sensor (HO2S) [Bank 1 / Sensor 1] signal input | Heated Oxygen Sensor (HO2S) [Bank 1 / Sensor 1] |
| 36 | ||
| 37 | ||
| 38 | Sensor ground | Camshaft Position Sensor (CMPS) |
| 39 | ||
| 40 | ||
| 41 | Camshaft Position Sensor (CMPS) signal input | Camshaft Position Sensor (CMPS) |
| 42 | ||
| 43 | ||
| 44 | Load signal input (Power Steering) | Power Steering Switch |
| 45 | ||
| 46 | A/C Pressure Switch signal input | A/C Control Module |
| 47 | ||
| 48 | For Autotransaxle Control | |
| 49 | ||
| 50 | For Autotransaxle Control | |
| 51 | Sensor ground | Throttle Position Sensor (TPS) |
| 52 | ||
| 53 | Fuel Level Sensor (FLS) signal input | Fuel Level Sensor (FLS) |
| 54 | ||
| 55 | ||
| 56 | ||
| 57 | For Autotransaxle Control | |
| 58 | ||
| 59 | ||
| 60 | For Autotransaxle Control | |
| 61 | For Autotransaxle Control | |
| 62 | For Autotransaxle Control | |
| 63 | For Autotransaxle Control | |
| 64 | For Autotransaxle Control | |
| 65 | For Autotransaxle Control | |
| 66 | For Autotransaxle Control | |
| 67 | For Autotransaxle Control | |
| 68 | For Autotransaxle Control | |
| 69 | ||
| 70 | For Autotransaxle Control | |
| 71 | For Autotransaxle Control | |
| 72 | For Autotransaxle Control | |
| 73 | Sensor ground | Engine Coolant Temperature Sensor (ECTS) |
| 74 | ||
| 75 | Throttle Position Sensor (TPS) signal input | Throttle Position Sensor (TPS) |
| 76 | ||
| 77 | Engine Coolant Temperature Sensor (ECTS) signal input | Engine Coolant Temperature Sensor (ECTS) |
| 78 | ||
| 79 | A/C Pressure Transducer signal input | A/C Pressure Transducer |
| 80 | For Autotransaxle Control | |
| 81 | For Autotransaxle Control | |
| 82 | For Autotransaxle Control | |
| 83 | For Autotransaxle Control | |
| 84 | For Autotransaxle Control | |
| 85 | ||
| 86 | ||
| 87 | For Autotransaxle Control | |
| 88 | For Autotransaxle Control | |
| 89 | For Autotransaxle Control | |
| 90 | For Autotransaxle Control | |
| 91 | For Autotransaxle Control | |
| 92 | For Autotransaxle Control | |
| 93 | ||
| 94 | For Autotransaxle Control |
CONNECTOR (C01-1) CONNECTION REFERENCE
CONNECTOR [C01-2]
| Pin | Description | Connected to |
|---|---|---|
| 1 | Ignition Coil (Cylinder #2) control output | Ignition Coil (Cylinder #2) |
| 2 | Ignition Coil (Cylinder #4) control output | Ignition Coil (Cylinder #4) |
| 3 | Fuel Tank Pressure Sensor (FTPS) signal input | Fuel Tank Pressure Sensor (FTPS) |
| 4 | ||
| 5 | ||
| 6 | Idle Speed Control Actuator (ISCA) [OPEN] control output | Idle Speed Control Actuator (ISCA) |
| 7 | Fuel Filler Cap "OPEN" Lamp control output | Fuel Filler Cap "OPEN" Lamp (Cluster) |
| 8 | Purge Control Solenoid Valve (PCSV) control output | Purge Control Solenoid Valve (PCSV) |
| 9 | Main Relay control output | Main Relay |
| 10 | ||
| 11 | Ignition switch signal input | Ignition switch |
| 12 | CAN [High] | Data Link Connector (DLC) |
| 13 | ||
| 14 | ||
| 15 | Knock Sensor [A] signal input | Knock Sensor |
| 16 | Ignition Coil (Cylinder #3) control output | Ignition coil (Cylinder #3) |
| 17 | Ignition Coil (Cylinder #1) control output | Ignition Coil (Cylinder #1) |
| 18 | ||
| 19 | ||
| 20 | ||
| 21 | Cooling Fan [Low] control output | Radiator Fan Relay |
| 22 | Idle Speed Control Actuator (ISCA) [CLOSE] control output | Idle Speed Control Actuator (ISCA) |
| 23 | Cooling Fan [High] control output | Condenser Fan Relay |
| 24 | Fuel consumption signal output | Trip computer |
| 25 | Engine speed signal output | Tachometer (Cluster) |
| 26 | ||
| 27 | CAN [Low] | Data Link Connector (DLC) |
| 28 | ||
| 29 | ||
| 30 | Knock Sensor [B] signal input | Knock Sensor |
| 31 | ||
| 32 | Immobilizer Lamp control output | Immobilizer Lamp (Cluster) |
| 33 | HO2S [Bank 1 / Sensor 2] heater control output | Heated Oxygen Sensor (HO2S) [Bank 1 / Sensor 2] |
| 34 | HO2S [Bank 1 / Sensor 1] heater control output | Heated Oxygen Sensor (HO2S) [Bank 1 / Sensor 1] |
| 35 | Canister Close Valve (CCV) control output | |
| 36 | Injector (Cylinder #3) control output | Injector (Cylinder #3) |
| 37 | Fuel Pump Relay output | Fuel Pump Relay |
| 38 | A/C Compressor Relay control output | A/C Compressor Relay |
| 39 | ||
| 40 | Crankshaft Position Sensor (CKPS) [A] signal input | Crankshaft Position Sensor (CKPS) |
| 41 | ||
| 42 | Reference supply (+5V) | Fuel Tank Pressure Sensor (FTPS) |
| 43 | ||
| 44 | Immobilizer Communication Line | Immobilizer Control Module |
| 45 | Wheel Speed Sensor (WSS) [+] signal input | Wheel Speed Sensor (WSS) [Without ABS] |
| 46 | ||
| 47 | ||
| 48 | Injector (Cylinder #4) control output | Injector (Cylinder #4) |
| 49 | CVVT Oil Control Valve (OCV) control output | CVVT Oil Control Valve (OCV) |
| 50 | Injector (Cylinder #1) control output | Injector (Cylinder #1) |
| 51 | Malfunction Indicator Lamp (MIL) control output | Malfunction Indicator Lamp (Cluster) |
| 52 | Injector (Cylinder #2) control output | Injector (Cylinder #2) |
| 53 | ||
| 54 | ||
| 55 | Crankshaft Position Sensor (CKPS) [B] signal input | Crankshaft Position Sensor (CKPS) |
| 56 | Battery power | Battery |
| 57 | Reference supply (+5V) | A/C Pressure Transducer |
| 58 | Reference supply (+5V) | Throttle Position Sensor (TPS) |
| 59 | ||
| 60 | Wheel Speed Sensor (WSS) [-] signal input | Wheel Speed Sensor (WSS) [Without ABS] |
CONNECTOR (C01-2) CONNECTION REFERENCE
3. PCM TERMINAL IN/OUT SIGNAL (A/T)
CONNECTOR [C01-1]
| Pin No. | Description | Condition | Type | Level | Test Result |
|---|---|---|---|---|---|
| 1 | Ground | Idle | DC | Max. 50mV | 0.0V |
| 2 | Ground | Idle | DC | Max. 50mV | 2.4mV |
| 3 | Ground | Idle | DC | Max. 50mV | 1.8mV |
| 4 | For Autotransaxle Control | ||||
| 5 | For Autotransaxle Control | ||||
| 6 | Batter voltage supply after main relay | IG OFF | DC | Max. 1.0V | 0V |
| IG ON | Battery Voltage | 12.81V | |||
| 7 | |||||
| 8 | Sensor ground | Idle | DC | Max. 50mV | 13.2mV |
| 9 | Sensor ground | Idle | DC | Max. 50mV | 8.9mV |
| 10 | Mass Air Flow Sensor (MAFS) signal input | Idle | Analog | 0~2.0V | 1.12V |
| 3000rpm | 1.0~4.5V | 1.96V | |||
| 11 | |||||
| 12 | |||||
| 13 | Heated Oxygen Sensor (HO2S) [Bank 1 / Sensor 2] signal input | Racing | Analog | Rich: 0.6~1.0V | 872mV |
| Lean: Max. 0.4V | 155mV | ||||
| 14 | |||||
| 15 | |||||
| 16 | |||||
| 17 | Load signal input (Defrost) | S/W OFF | DC | Max. 0.5V | 0mV |
| S/W ON | Battery Voltage | 13.19V | |||
| 18 | |||||
| 19 | |||||
| 20 | Vehicle speed signal input [With ABS] | Vehicle Run | Pulse | HI: Min. 5.0V | 12.4V |
| LO: Max. 1.0V | 17mV | ||||
| 432Hz at 30kph | |||||
| 21 | |||||
| 22 | Load signal input (Head Lamp) | S/W OFF | DC | Battery Voltage | 12.96V |
| S/W ON | Max. 0.5V | 274mV | |||
| 23 | A/C switch signal input | S/W OFF | DC | Max. 1.0V | 10.6mV |
| S/W ON | Battery Voltage | 11.78V | |||
| 24 | Ground (For Autotransaxle) | Idle | DC | Max. 50mV | 2.1mV |
| 25 | Ground (For Autotransaxle) | Idle | DC | Max. 50mV | 1.8mV |
| 26 | For Autotransaxle Control | ||||
| 27 | For Autotransaxle Control | ||||
| 28 | |||||
| 29 | Sensor ground | Idle | DC | Max. 50 mV | 9.2 mV |
| 30 | Ground | Idle | DC | Max. 50mV | 8.7mV |
| 31 | Sensor ground | Idle | DC | Max. 50mV | 7.2mV |
| 32 | Intake Air Temperature Sensor (IATS) signal input | Idle | Analog | 0~5V | 2.48V at 24 °C |
| 33 | |||||
| 34 | |||||
| 35 | Heated Oxygen Sensor (HO2S) [Bank 1 / Sensor 1] signal input | Racing | Analog | Rich: 0.6~1.0V | 880mV |
| Lean: Max. 0.4V | 208mV | ||||
| 36 | |||||
| 37 | |||||
| 38 | Sensor ground | Idle | DC | Max. 50mV | 3.7mV |
| 39 | |||||
| 40 | |||||
| 41 | Camshaft Position Sensor (CMPS) signal input | Idle | Pulse | HI: Battery Voltage | 13.86V |
| LO: Max. 0.5V | 450mV | ||||
| 42 | |||||
| 43 | |||||
| 44 | Load signal input (Power Steering) | S/W ON | DC | Battery Voltage | 11.81V |
| S/W OFF | Max. 0.5V | 351mV | |||
| 45 | |||||
| 46 | A/C Pressure Switch signal input | S/W OFF | DC | Max. 1.0V | 0.0mV |
| S/W ON | Battery Voltage | 12.77V | |||
| 47 | |||||
| 48 | For Autotransaxle Control | ||||
| 49 | |||||
| 50 | For Autotransaxle Control | ||||
| 51 | Sensor ground | Idle | DC | Max. 50mV | 6.8mV |
| 52 | |||||
| 53 | Fuel Level Sensor (FLS) signal input | IG ON | DC | 0~Battery Voltage | 2.14V |
| 54 | |||||
| 55 | |||||
| 56 | |||||
| 57 | For Autotransaxle Control | ||||
| 58 | |||||
| 59 | |||||
| 60 | For Autotransaxle Control | ||||
| 61 | For Autotransaxle Control | ||||
| 62 | For Autotransaxle Control | ||||
| 63 | For Autotransaxle Control | ||||
| 64 | For Autotransaxle Control | ||||
| 65 | For Autotransaxle Control | ||||
| 66 | For Autotransaxle Control | ||||
| 67 | For Autotransaxle Control | ||||
| 68 | For Autotransaxle Control | ||||
| 69 | |||||
| 70 | For Autotransaxle Control | ||||
| 71 | For Autotransaxle Control | ||||
| 72 | For Autotransaxle Control | ||||
| 73 | Sensor ground | Idle | DC | Max. 50mV | 2.1mV |
| 74 | |||||
| 75 | Throttle Position Sensor (TPS) signal input | C.T | Analog | 0.2~0.7V | 0.31V |
| W.O.T | Min. 4.0V | 4.21V | |||
| 76 | |||||
| 77 | Engine Coolant Temperature Sensor (ECTS) signal input | Idle | Analog | 0.5~4.5V | 0.85V at 95.1 °C |
| 78 | |||||
| 79 | A/C Pressure Transducer signal input | A/C ON | Analog | Max. 4.8V | 2.51V |
| 80 | For Autotransaxle Control | ||||
| 81 | For Autotransaxle Control | ||||
| 82 | For Autotransaxle Control | ||||
| 83 | For Autotransaxle Control | ||||
| 84 | For Autotransaxle Control | ||||
| 85 | |||||
| 86 | For Autotransaxle Control | ||||
| 87 | For Autotransaxle Control | ||||
| 88 | For Autotransaxle Control | ||||
| 89 | For Autotransaxle Control | ||||
| 90 | For Autotransaxle Control | ||||
| 91 | For Autotransaxle Control | ||||
| 92 | For Autotransaxle Control | ||||
| 93 | |||||
| 94 | For Autotransaxle Control |
CONNECTOR (C01-1) TERMINALS IN/OUT SIGNAL
CONNECTOR [C01-2]
| Pin No. | Description | Condition | Type | Level | Test Result |
|---|---|---|---|---|---|
| 1 | Ignition Coil (Cylinder #2) control output | Idle | Pulse | 1st Voltage: 300~400V | 365V |
| ON Voltage: Max. 2V | 1.69V | ||||
| 5.0Hz | |||||
| 2 | Ignition Coil (Cylinder #4) control output | Idle | Pulse | 1st Voltage: 300~400V | 362V |
| ON Voltage: Max. 2V | 1.69V | ||||
| 5.0Hz | |||||
| 3 | Fuel Tank Pressure Sensor (FTPS) signal input | Idle | DC | 0.4~4.6V | 2.45V |
| 4 | |||||
| 5 | |||||
| 6 | Idle Speed Control Actuator (ISCA) [OPEN] control output | Idle | Pulse | HI: Battery Voltage | 14.8V |
| LO: Max. 1.0V | 128mV | ||||
| 250 Hz at duty 32.5% | |||||
| 7 | Fuel Filler camp "OPEN" Lamp control output | Lamp OFF | DC | Battery Voltage | |
| Lamp ON | Max 1.0V | ||||
| 8 | Purge Control Solenoid Valve (PCSV) control output | Active Inactive | Pulse | HI: Battery Voltage | 14.2V |
| LO: Max. 1.0V | 215mV | ||||
| Vpeak: Max. 70V | 45.2V | ||||
| 13.68Hz | |||||
| 9 | Main Relay control output | Relay OFF | DC | Battery Voltage | 12.97V |
| Relay ON | Max. 1.0V | 791mV | |||
| 10 | |||||
| 11 | Ignition switch signal input | IG OFF | DC | Max 0.5V | 2.8mV |
| IG ON | Battery Voltage | 12.18V | |||
| 12 | CAN [High] | Recessive | Pulse | 2.0~3.0V | 2.36V |
| Dominant | 2.75~4.5V | 3.44V | |||
| 13 | |||||
| 14 | |||||
| 15 | Knock Sensor [A] signal input | Knocking | Variable Frequency | ||
| Normal | |||||
| 16 | Ignition Coil (Cylinder #3) control output | Idle | Pulse | 1st Voltage: 300~400V | 358V |
| ON Voltage: Max. 2V | 1.68V | ||||
| 5.0Hz | |||||
| 17 | Ignition Coil (Cylinder #1) control output | Idle | Pulse | 1st Voltage: 300~400V | 349V |
| ON Voltage: Max. 2V | 1.68V | ||||
| 5.0Hz | |||||
| 18 | |||||
| 19 | |||||
| 20 | |||||
| 21 | Cooling Fan [Low] control output | Relay OFF | DC | Battery Voltage | 14.05V |
| Relay ON | Max. 1.0V | 52.1mV | |||
| 22 | Idle Speed Control Actuator (ISCA) [CLOSE] control output | Idle | Pulse | HI: Battery Voltage | 14.9V |
| LO: Max. 1.0V | 204mV | ||||
| 250Hz at duty 67.5% | |||||
| 23 | Cooling Fan [High] control output | Relay OFF | DC | Battery Voltage | 14.12V |
| Relay ON | Max. 1.0V | 198mV | |||
| 24 | Fuel consumption signal output | Idle | Pulse | HI: Battery Voltage | 13.9V |
| LO: Max. 0.5V | 16.1mV | ||||
| 25 | Engine speed signal output | Idle | Pulse | HI: Battery Voltage | 13.9V |
| LO: Max. 0.5V | 12.1mV | ||||
| 20~26Hz | 21.9Hz | ||||
| 26 | |||||
| 27 | CAN [Low] | Recessive | Pulse | 2.0~3.0V | 2.36V |
| Dominant | 0.5~2.25V | 1.44V | |||
| 28 | |||||
| 29 | |||||
| 30 | Knock Sensor [B] signal input | Knocking | Variable Frequency | ||
| Normal | |||||
| 31 | |||||
| 32 | Immobilizer Lamp control output | Lamp OFF | DC | Battery Voltage | 11.98V |
| Lamp ON | Max. 1.0V | 27mV | |||
| 33 | HO2S [Bank 1 / Sensor 2] heater control output | Engine Run | Pulse (2Hz) | HI: Battery Voltage | 14.1V |
| LO: Max. 1.0V | 304mV | ||||
| 34 | HO2S [Bank 1 / Sensor 1] heater control output | Engine Run | Pulse (2Hz) | HI: Battery Voltage | 14.1V |
| LO: Max. 1.0V | 326mV | ||||
| 35 | Canister Close Valve (CCV) control output | Active Inactive | Pulse | HI: Battery Voltage | 12.5V |
| LO: Max. 1.0V | 121 mV | ||||
| Vpeak: Max. 70V | 44.7V | ||||
| 36 | Injector (Cylinder #3) control output | Idle | Pulse (5.5Hz) | HI: Battery Voltage | 14.2V |
| LO: Max. 1.0V | 330mV | ||||
| Vpeak: Max. 80V | 69.6V | ||||
| 37 | Fuel Pump Relay output | Relay OFF | DC | Battery Voltage | 12.3V |
| Relay ON | Max. 1.0V | 30mV | |||
| 38 | A/C Compressor Relay control output | A/C OFF | DC | Battery Voltage | 14.32V |
| A/C ON | Max. 1.0V | 114mV | |||
| 39 | |||||
| 40 | Crankshaft Position Sensor (CKPS) [A] signal input | Idle | Sine Wave | Vp_p: Min. 1.0V | 8.44V |
| 718.4Hz | |||||
| 41 | |||||
| 42 | Reference Supply (+5V) | IG OFF | DC | Max. 0.5V | |
| IG ON | 4.9~5.1V | ||||
| 43 | Reference supply (+5V) | IG OFF | DC | Max. 0.5V | |
| IG ON | 4.9~5.1V | ||||
| 44 | Immobilizer Communication Line | When communication after IG ON | Pulse | HI: Min. 8.5V | 12.31V |
| LO: Max. 3.5V | 1.17V | ||||
| 45 | Wheel Speed Sensor (WSS) [+] signal input [Without ABS] | Vehicle Run | Sine Wave | Vp_p: Min. 0.2V | |
| 46 | |||||
| 47 | |||||
| 48 | Injector (Cylinder #4) control output | Idle | Pulse (5.5Hz) | HI: Battery Voltage | 14.2V |
| LO: Max. 1.0V | 330mV | ||||
| Vpeak: Max. 80V | 69.6V | ||||
| 49 | CVVT Oil Control Valve (OCV) control output | Idle | Pulse | HI: Battery Voltage | 14.9V |
| LO: Max. 1.0V | 36.2mV | ||||
| 300.26Hz at duty 6.1% | |||||
| 50 | Injector (Cylinder #1) control output | Idle | Pulse (5.5Hz) | HI: Battery Voltage | 14.2V |
| LO: Max. 1.0V | 330mV | ||||
| Vpeak: Max. 80V | 69.6V | ||||
| 51 | Malfunction Indicator Lamp (MIL) control output | Lamp OFF | DC | Battery Voltage | 13.03V |
| Lamp ON | Max. 1.0V | 716mV | |||
| 52 | Injector (Cylinder #2) control output | Idle | Pulse (5.5Hz) | HI: Battery Voltage | 13.6V |
| LO: Max. 1.0V | 340mV | ||||
| Vpeak: Max. 80V | 69.7V | ||||
| 53 | |||||
| 54 | |||||
| 55 | Crankshaft Position Sensor (CKPS) [B] signal input | Idle | Sine Wave | Vp_p: Min.1.0V | 8.44V |
| 718.4Hz | |||||
| 56 | Battery power | Always | DC | Battery Voltage | 12.91V |
| 57 | Reference supply (+5V) | IG OFF | DC | Max. 0.5V | 4.2mV |
| IG ON | 4.9~5.1V | 5.04V | |||
| 58 | Reference supply (+5V) | IG OFF | DC | Max. 0.5V | 0.0mV |
| IG ON | 4.9~5.1V | 5.04V | |||
| 59 | |||||
| 60 | Wheel Speed Sensor (WSS) [-] signal input [Without ABS] | Vehicle Run | Sine Wave | Vp-p: Min. 0.2V |
CONNECTOR (C01-2) TERMINALS IN/OUT SIGNALS
Scheme 27
2. ECM TERMINAL FUNCTION (M/T)
CONNECTOR [C01]
| Pin | Description | Connected to |
|---|---|---|
| 1 | Ignition Coil (Cylinder #1) control output | Ignition Coil (Cylinder #1) |
| 2 | Ground | Chassis Ground |
| 3 | Ignition Coil (Cylinder #3) control output | Ignition Coil (Cylinder #3) |
| 4 | ||
| 5 | ||
| 6 | Batter voltage supply after main relay | Main Relay |
| 7 | Ignition Coil (Cylinder #4) control output | Ignition Coil (Cylinder #4) |
| 8 | A/C Pressure Switch signal input | A/C Control Module |
| 9 | ||
| 10 | Load signal input (Power Steering) | Power Steering Switch |
| 11 | Knock Sensor [A] signal input | Knock Sensor |
| 12 | Sensor ground | Throttle Position Sensor (TPS) |
| 13 | ||
| 14 | ||
| 15 | Sensor ground | MAFS & IATS |
| 16 | Sensor ground | Heated Oxygen Sensor (HO2S) [Bank 1 / Sensor 2] |
| 17 | Sensor ground | Camshaft Position Sensor (CMPS) |
| 18 | Immobilizer Communication Line | Immobilizer Control Module |
| 19 | Mass Air Flow Sensor (MAFS) signal input | Mass Air Flow Sensor (MAFS) |
| 20 | ||
| 21 | ||
| 22 | Main Relay control output | Main Relay |
| 23 | Cooling Fan [High] control output | Condenser Fan Relay |
| 24 | Injector (Cylinder #3) control output | Injector (Cylinder #3) |
| 25 | Idle Speed Control Actuator (ISCA) [CLOSE] control output | Idle Speed Control Actuator (ISCA) |
| 26 | ||
| 27 | ||
| 28 | Cooling Fan [Low] control output | Radiator Fan Relay |
| 29 | Ignition Coil (Cylinder #2) control output | Ignition Coil (Cylinder #2) |
| 30 | A/C switch signal input | A/C Control Module |
| 31 | Load signal input (Head Lamp) | Multi Function Switch |
| 32 | Knock Sensor [B] signal input | Knock Sensor |
| 33 | Ground | A/C Pressure Transducer |
| 34 | Sensor ground | Fuel Tank Pressure Sensor (FTPS) |
| 35 | Sensor ground | Engine Coolant Temperature Sensor (ECTS) |
| 36 | Heated Oxygen Sensor (HO2S) [Bank 1 / Sensor 2] signal input | Heated Oxygen Sensor (HO2S) [Bank 1 / Sensor 2] |
| 37 | ||
| 38 | Sensor ground | Heated Oxygen Sensor (HO2S) [Bank 1 / Sensor 1] |
| 39 | Throttle Position Sensor (TPS) signal input | Throttle Position Sensor (TPS) |
| 40 | A/C Pressure Transducer signal input | A/C Pressure Transducer |
| 41 | ||
| 42 | ||
| 43 | Intake Air Temperature Sensor (IATS) signal input | Intake Air Temperature Sensor (IATS) |
| 44 | ||
| 45 | A/C Compressor Relay control output | A/C Compressor Relay |
| 46 | Fuel Pump Relay output | Fuel Pump Relay |
| 47 | Injector (Cylinder #2) control output | Injector (Cylinder #2) |
| 48 | Immobilizer Lamp control output | Immobilizer Lamp (Cluster) |
| 49 | Canister Close Valve (CCV) control output | Canister Close Valve (CCV) |
| 50 | Fuel Tank Pressure Sensor (FTPS) signal input | Fuel Tank Pressure Sensor (FTPS) |
| 51 | Ground | Chassis Ground |
| 52 | ||
| 53 | ||
| 54 | Heated Oxygen Sensor (HO2S) [Bank 1 / Sensor 1] signal input | Heated Oxygen Sensor (HO2S) [Bank 1 / Sensor 1] |
| 55 | ||
| 56 | ||
| 57 | ||
| 58 | Wheel Speed Sensor (WSS) [+] signal input | Wheel Speed Sensor (WSS) [Without ABS] |
| 59 | Reference supply (+5V) | A/C Pressure Transducer |
| 60 | Reference supply (+5V) | Throttle Position Sensor (TPS) |
| 61 | ||
| 62 | CAN [Low] | Data Link Connector (DLC) |
| 63 | Camshaft Position Sensor (CMPS) signal input | Camshaft Position Sensor (CMPS) |
| 64 | Vehicle speed signal input | ABS Control Module [With ABS] |
| 65 | ||
| 66 | Load signal input (Defrost) | Defrost Relay |
| 67 | Engine speed signal output | Tachometer (Cluster) |
| 68 | Injector (Cylinder #4) control output | Injector (Cylinder #4) |
| 69 | Purge Control Solenoid Valve (PCSV) control output | Purge Control Solenoid Valve (PCSV) |
| 70 | Malfunction Indicator Lamp (MIL) control output | Malfunction Indicator Lamp (Cluster) |
| 71 | HO2S [Bank 1 / Sensor 2] heater control output | Heated Oxygen Sensor (HO2S) [Bank 1 / Sensor 2] |
| 72 | HO2S [Bank 1 / Sensor 1] heater control output | Heated Oxygen Sensor (HO2S) [Bank 1 / Sensor 1] |
| 73 | Ground | Chassis Ground |
| 74 | ||
| 75 | ||
| 76 | Fuel Level Sensor (FLS) signal input | Fuel Level Sensor (FLS) |
| 77 | Engine Coolant Temperature Sensor (ECTS) signal input | Engine Coolant Temperature Sensor (ECTS) |
| 78 | ||
| 79 | Wheel Speed Sensor (WSS) [-] signal input | Wheel Speed Sensor (WSS) [Without ABS] |
| 80 | Reference supply (+5V) | Fuel Tank Pressure Sensor (FTPS) |
| 81 | ||
| 82 | Battery power | Battery |
| 83 | Ignition switch signal input | Ignition switch |
| 84 | CAN [High] | Data Link Connector (DLC) |
| 85 | ||
| 86 | Crankshaft Position Sensor (CKPS) [B] signal input | Crankshaft Position Sensor (CKPS) |
| 87 | Crankshaft Position Sensor (CKPS) [A] signal input | Crankshaft Position Sensor (CKPS) |
| 88 | Fuel consumption signal output | Trip computer |
| 89 | ||
| 90 | Idle Speed Control Actuator (ISCA) [OPEN] control output | Idle Speed Control Actuator (ISCA) |
| 91 | Injector (Cylinder #1) control output | Injector (Cylinder #1) |
| 92 | CVVT Oil Control Valve (OCV) control output | CVVT Oil Control Valve (OCV) |
| 93 | ||
| 94 | Fuel Filler Cap "OPEN" Lamp control output | Fuel Filler Cap "OPEN" Lamp (Cluster) |
CONNECTOR (C01) CONNECTION REFERENCE
