Fuses & Relays: Other Kia Rio II

Fuses & Circuit Breakers 15 illustrations ~816 words

Fuse & Relay Index Information

For fuse locations within the engine compartment fuse/relay box see scheme 3

Use designated fuses only.

DescriptionFuse RatingProtected Components
MAIN120AAlternator
BATT-150AI/P Junction Box
BLOWER40ABlower Relay
ABS -140AABS Control Module, ESP Control Module
ABS -240AABS Control Module, ESP Control Module
IGN -240AStart Relay, Ignition Switch
IGN -130AIgnition Switch, Horn Relay, ICM Relay Box
BATT-230AI/P Junction Box
P/WDW30AI/P Junction Box
RAD30ARadiator Fan Relay
ECU A30AMain Relay
ECU C20AECM
FUEL CUT20AFuel Pump Relay
INJ15ACanister Purge Control Valve, CVVT Oil Control Valve, Injector-1,-2,-3,-4, Idle Speed Control Actuator, Immobilizer Control Module
A/CON -110AA/CON Relay
A/CON -210AA/CON Control Module, Blower Motor
ECU B10AECM
HORN15AHorn Relay, Siren Relay
SNSR10AA/CON Relay, RAD Fan Relay, Cond Fan Relay -1, -2
COND30ARAD Fan Relay, Cond Fan Relay -1, -2

IDENTIFYING FUSES & RELAYS (ENGINE COMPARTMENT FUSE & RELAY BOX)

DescriptionFuse RatingProtected Components
HORNHorn Relay
MAINMain Relay
FUEL PUMPFuel Pump Relay
RAD FANRadiator Fan Relay
COND FAN 2Condenser Fan Relay
FUEL HTRFuel Filter Heater Relay
BLOWERBlower Motor Relay
STARTStarter Motor Relay
COND FAN 1Condenser Fan Relay
A/CONAir Conditioner Relay

IDENTIFYING RELAYS (ENGINE COMPARTMENT FUSE & RELAY BOX)

POWER RELAY (TYPE A)

Check for continuity between the terminals.

Scheme 5

Scheme 5: POWER RELAY (TYPE A)
Scheme 5: POWER RELAY (TYPE A)

Scheme 6

Scheme 6
Scheme 6
  1. There should be continuity between the No.1 and No.2 terminals when power and ground are connected to the No.3 and No.4 terminals.
  2. There should be no continuity between the No.1 and No.2 terminals when power is disconnected.

POWER RELAY (TYPE B)

Check for continuity between the terminals.

Scheme 7

Scheme 7: POWER RELAY (TYPE B)
Scheme 7: POWER RELAY (TYPE B)

Scheme 8

Scheme 8
Scheme 8
  1. There should be continuity between the No.1 and No.2 terminals when power and ground are connected to the No.3 and No.5 terminals.
  2. There should be continuity between the No.1 and No.4 terminals when power is disconnected.

POWER RELAY (TYPE C)

Check for continuity between the terminals.

Scheme 9

Scheme 9: POWER RELAY (TYPE C)
Scheme 9: POWER RELAY (TYPE C)

Scheme 10

Scheme 10
Scheme 10
  1. There should be continuity between the No.1 and No.4 terminals when power and ground are connected to the No.2 and No.3 terminals.
  2. There should be no continuity between the No.1 and No.4 terminals when power is disconnected.
  1. Be sure there is no play in the fuse holders, and that the fuses are held securely.
  2. Are the fuse capacities for each circuit correct?
  3. Are there any blown fuses? If a fuse is to be replaced, be sure to use a new fuse of the same capacity. Always determine why the fuse blew first and completely eliminate the problem before installing a new fuse.

Scheme 11

Scheme 11: COMPONENTS
Scheme 11: COMPONENTS

Scheme 12

Scheme 12
Scheme 12

Fuse Index Information

For fuse locations within the passenger compartment fuse/relay box (Scheme 12)

Use designated fuses only.

DescriptionFuse RatingProtected Components
RR WIPER15ARear wiper
H/LP(LH)10AHeadlight (left)
FR WIPER25AFront wiper
BLOWER10ABlower
H/LP(RH)10AHeadlight (right)
S/ROOF20ASunroof
STOP LP15AStop light
C/DR LOCK20ACentral door lock
IGN COIL15AIgnition coil
ABS10AABS
B/UP LP10ABack-up light
SPARESpare fuse
C/LIGHTER25ACigarette lighter
FOLD'G10AOutside rearview mirror folding
HTD SEAT20ASeat warmer
AMP25AAmplifier
FR FOG LP10AFront fog light
SPARESpare fuse
ECU10AEngine control unit
CLUSTER10ACluster
P/WDW RH25APower window (right)
AUDIO10AAudio
RR FOG LP10ARear fog light
IGN10AIgnition
HTD GLASS30ARear window defroster
A/BAG15AAirbag
TCU10AAutomatic transaxle control
SNSR10ASensors
SPARESpare fuse
MULT B/UP10ACluster, ETACS, A/C, Clock, Room lamp
AUDIO15AAudio
P/WDW LH25APower window (left)
HTD MIRR10AOutside rearview mirror heater
TAIL LP(LH)10ATaillight (left)
TAIL LP(RH)10ATaillight (right)
HAZARD10AHazard warning light
T/SIG LP10ATurn signal light
A/BAG IND10AAir bag warning
START10AStarter motor

IDENTIFYING FUSES (PASSENGER COMPARTMENT FUSE BOX)

Memory Fuse

This vehicle is equipped with a memory fuse to prevent battery discharge if the vehicle is parked without being operated for prolonged periods. Use the following procedures before parking the vehicle for prolonged period.

  1. Turn off the engine.
  2. Turn off the headlights and tail lights.
  3. Open the passenger room fuse box cover and pull up the MULT B/UP 10A / AUDIO 15A combined holder fuses 30 and 31. (Scheme 12)

Note. If the memory fuse is pulled up from the fuse panel, the warning chime, audio, clock and interior lamps, etc., will not operate. Some items must be reset after fuse replacement. Even though the memory fuse is pulled up, the battery can still be discharged by operation of the headlights or other electrical devices.

Check for continuity between the terminals.

Scheme 13

Scheme 13: POWER RELAY (TYPE A)
Scheme 13: POWER RELAY (TYPE A)

Scheme 14

Scheme 14
Scheme 14
  1. There should be continuity between the No.1 and No.2 terminals when power and ground are connected to the No.3 and No.4 terminals.
  2. There should be no continuity between the No.1 and No.2 terminals when power is disconnected.

Check for continuity between the terminals.

Scheme 15

Scheme 15: POWER RELAY (TYPE B)
Scheme 15: POWER RELAY (TYPE B)
  1. There should be continuity between the No.1 and No.2 terminals when power and ground are connected to the No.3 and No.5 terminals.
  2. There should be continuity between the No.1 and No.4 terminals when power is disconnected.

Check for continuity between the terminals.

Scheme 16

Scheme 16: POWER RELAY (TYPE C)
Scheme 16: POWER RELAY (TYPE C)

Scheme 17

Scheme 17
Scheme 17
  1. There should be continuity between the No.1 and No.4 terminals when power and ground are connected to the No.2 and No.3 terminals.
  2. There should be no continuity between the No.1 and No.4 terminals when power is disconnected.
  1. Be sure there is no play in the fuse holders, and that the fuses are held securely.
  2. Are the fuse capacities for each circuit correct?
  3. Are there any blown fuses? If a fuse is to be replaced, be sure to use a new fuse of the same capacity. Always determine why the fuse blew first and completely eliminate the problem before installing a new fuse.

Scheme 18

Scheme 18: REPLACEMENT
Scheme 18: REPLACEMENT

Scheme 19

Scheme 19
Scheme 19
  1. Disconnect the negative (-) battery terminal.
  2. Remove the crash pad lower panel (A) (Refer to «INTERIOR»(ref-269624) - crash pad ). Avoid damaging retaining clips (B).
  3. Disconnect the connectors of junction box and loosen the ground cable (A).
  4. Remove the junction box (B) after loosening the mounting nuts (2EA).
  5. Installation is the reverse of removal procedures.

HAZARD LAMP RELAY

Check for continuity between the terminals.

  1. There should be continuity between the No.8 and No.6 terminals when power and ground are connected to the No.8 and No.9 terminals.
  2. There should be no continuity between the No.8 and No.6 terminals when power is disconnected.

BURGLAR ALARM HORN

Check for continuity between the terminals.

  1. There should be continuity between the No. 11 and No.4 terminals when power and ground are connected to the No.11 and No.3 terminals.
  2. There should be no continuity between the No. 11 and No.4 terminals when power is disconnected.

BURGLAR ALARM

Check for continuity between the terminals.

  1. There should be no continuity between the No.1 and No.5 terminals when power and ground are connected to the No.1 and No.2 terminals.
  2. There should be continuity between the No.1 and No.5 terminals when power is disconnected.
