Lighting System: Specifications Kia Rio II

Exterior Lights 2 illustrations

SPECIFICATION

ItemsBulb Wattage (W)
Head lamp (High/Low)60/55
Front turn signal lamp27
Front position lamp5
Front fog lamp27
Rear tail/stop lamp27/8
Back up lamp18
Rear turn signal lamp27
License plate lamp5
Side marker5
Room lamp10
Overhead console lamp10 x 2
High mounted stop lamp18
Luggage lamp5

ITEM SPECIFICATION

Scheme 1

Scheme 1: REPLACEMENT
Scheme 1: REPLACEMENT

Scheme 2

Scheme 2
Scheme 2
  1. Disconnect the negative (-) battery terminal.
  2. Loose the mounting bolts (2EA) and nut of head lamp.
  3. Remove the head lamp assembly after disconnecting the lamp connectors. NOTE: Take care that holding clip (A) is not to be damaged.
  4. Installation is the reverse of removal.
