Blower Controls: Diagnosis Kia Rio II

Automatic HVAC System 6 illustrations ~143 words

INSPECTION

Check for continuity between the terminals.

Scheme 14

Scheme 14: INSPECTION

Scheme 15

Scheme 15
  1. There should be continuity between No1 and No.4 terminals when power and ground are connected to No.2 and No.3 terminals.
  2. There should be no continuity between No.1 and No.4 terminals when power is disconnected.
  3. If the blower motor voltage is not operated well, substitute with a known-good blower relay and check for proper operation.
  4. If the problem is corrected, replace the blower relay.

Scheme 16

Scheme 16: COMPONENT LOCATION

Scheme 17

Scheme 17: INSPECTION

Scheme 18

Scheme 18
  1. Measure terminal-to-terminal resistance of the blower resistor.
  2. If measured resistance is not within specification, the blower resistor must be replaced. (After removing the resistor)

Scheme 19

Scheme 19: REPLACEMENT
  1. Disconnect the negative (-) battery terminal.
  2. Disconnect the blower resistor connector (A) at the connecting part blower unit.
  3. Remove the blower resistor after loosening the mounting screws.
  4. Installation is the reverse order of removal.
