Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
- Disconnect the negative (-) battery terminal.
- Remove the driver crash pad lower panel. Refer to «CRASH PAD LOWER PANEL REPLACEMENT»(ref-675198-S26491761052014120400000) .
- Remove the steering column upper and lower shrouds. Refer to «SHROUD REPLACEMENT»(ref-675198-S40807363212014120400000) .
- Remove the wiper switch. Refer to «REMOVAL»(ref-675221-S33669874962014120400000) .
- Remove the ignition switch after disconnecting the ignition switch 6P connector (A)
- Remove the key warning/immobilizer connector (A).
- After loosening the screw, remove the key warning switch and key Illumination (A).
- Pushing lock pin with key ACC.
- Remove the key lock cylinder (A).
Installation
- Install the key lock cylinder.
- Install the key warning switch and key Illumination.
- Install the key warning/immobilizer connector.
- Connect the ignition switch connector after Install the ignition switch.
- Install the wiper switch.
- Install the steering column shrouds.
- Install the driver crash pad lower panel.
Scheme 6
Scheme 7
Scheme 8
- Disconnect the ignition switch connector (A) and key warning switch connector (B) from the steering column.
- Check for continuity between the terminals.
- If continuity is not specified, replace the switch.
