Inspection With GDS
Initialization and diagnosis sequence by using GDS equipment.
Below content summarize the procedure for A/S using GDS.
| No. | Procedure |
|---|---|
| 1 | Locate vehicle to flat plane |
| 2 | Tire check |
| 3 | IGN1 ON |
| 4 | Head lamp Low Beam ON |
| 5 | Connection with diagnostic tool |
| 6 | Initial command by diagnostic tool |
| 7 | Clear DTC Code |
| 8 | IGN1 OFF --> ON |
| 9 | Re-Connection with diagnostic tool |
| 10 | Checking of HLLD output value as 15% and DTC Code |
| 11 | HLLD actuating by diagnostic tool command |
| 12 | Head lamp mechanical Initial Aiming |
REPAIR PROCEDURES TABLE
Note. There's no loads in vehicle and vehicle should be on flat plane. Should check of HLLD output value after initial setting. Should do first electrical initial setting by diagnostic tool and then mechanical aiming afterward.
Scheme 89
Scheme 90
Scheme 91
Scheme 92
Scheme 93
Scheme 94
Scheme 95
Scheme 96
- Select the vehicle model and "Head lamp leveling".
- GDS can operates actuator forcefully, input/output value monitoring and self diagnosis.
- To perform functional test on AHLS outputs, select "Actuation Test".
- Select "Parameter setting & Zero position Initial".
- Confirm that AHLS operate forcefully in "Head lamp leveling" menu.
- To check the DTC of the head lamp leveling system, select "Diagnostic trouble codes"
Scheme 97
- Disconnect the negative (-) battery terminal.
- Remove the head lamp assembly. Refer to REMOVAL .
- Remove the head lamp leveling actuator (A) by loosening the adjusting bolt (B) after rotating it to an arrow direction.
- Installation is the reverse of removal procedure.
Scheme 98
Inspection
- Ignition "ON".
- Turn on the head lamp switch.
- Check for operation. If the aim of the head lamps changes smoothly when the head lamp leveling switch is turned.
- If the operation does not work well, inspect the connector and terminals to be sure they are all making good contact. If the terminals are bent, loose or corroded, repair them as necessary and recheck the system. If the terminals look OK, go to step 5 .
- Substitute with a known-good head lamp assembly and check for proper operation.
Scheme 99
- Remove the head lamp leveling unit connector (A).
- Loosen the mounting bolts (3 EA) of automatic head lamp leveling unit assembly. Tightening torque: 6.86±1.96 Nm (0.7±0.2 kgf.m, 5.06±1.44 lb.ft)
- Remove the head lamp leveling unit assembly.
