Engine Cooling System - Optima Hev: Specifications Kia Optima III рестайлинг

Cooling System (Mechanical) 12 illustrations ~152 words

Specifications

ItemsSpecifications
Operating temperature22~185°F (-30~85°C)
Operating voltageDC 9~16V
Rated voltageDC 12V
Rated current (No load)300mA or less

Scheme 1

Scheme 1
Scheme 1

Scheme 2

Scheme 2: Components
Scheme 2: Components

Scheme 3

Scheme 3: Schematic Diagram
Scheme 3: Schematic Diagram

Scheme 4

Scheme 4: Circuit Diagram
Scheme 4: Circuit Diagram

Scheme 5

Scheme 5: Removal
Scheme 5: Removal

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8
  1. Remove the front bumper. (Refer to " «FRONT BUMPER»(ref-675067-S20939142622014120400000) ")
  2. Remove the headlamps. (Refer to " «HEAD LAMPS»(ref-675066-S21694088742014120400000) ")
  3. Remove the air guards (A).
  4. Unfasten the 2 bolts (A) and 2 fasteners (B).
  5. Disconnect the AAF (Active air flap) actuator connector (A).
  6. Remove the AAF (Active air flap) assembly (A).
  7. Installation is the reverse of removal.

Scheme 9

Scheme 9: Disassembly
Scheme 9: Disassembly

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12
  1. Separate the duct (A) from the AAF (Active air flap) (B).
  2. Remove the actuator cover (A) from the housing (B).
  3. Remove the actuator (A) from the housing (B).
  4. Remove the link (A) and flaps (B) from the housing (C).
  5. Assembly is the reverse of disassembly.

Note. When assembling, the link and flaps should be in full open position.
