Body Control Module (BCM) - Optima Hev: Other Kia Optima III рестайлинг

Function

1. Wiper Control Front Wiper Control Function
2. Warning Control Driver Seat Belt Reminder Control Function Assist Seat Belt Reminder Control Function Key Operated Warning Control Function Parking Brake Warning Control Function
3. Lamp Control Keyhole Illumination Control Function Room Lamp Control Function Foot Lamp Control Function Head Lamp Control Function Tail Lamp Control Function Tail Lamp Auto Cut Control Function Head Lamp Welcome Control Function Escort Control Function Front Fog Control Function DRL Control Function (CANADA) Dedicated DRL Lamp Control Function Auto Light Control Function Static Bending Head Lamp Control Function
4. Time Control Power Window Timer Control Function Front Deicer Control Function Rear Defogger Control Function
5. Door Lock/Unlock Control Central Door Lock/Unlock Control Function Central Door Lock Control Function Speed Sensing Auto Door Lock (UMS) Key Remove Auto Door Unlock (UMS) Shift Lever Not 'P' Lock (UMS) Two Turn Unlock Control Function Key Reminder Control Function Crash Unlock Control Function Trunk Release Control Function
6. Outside Mirror Control Auto Folding Control Function
7. Horn Control Burglar Alarm Control Function Panic Control Function Horn Answer Back Control Function
8. Others Smart Key Control Function ATM Shift Lock Control Function Key Interlock Control Function AV Tail Control Function PAS/RPAS Control Function Diagnosis TMU

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

1. The body control module can diagnose by using the GDS more quickly. The BCM communicates with the GDS and then reads the input/output value and drives the actuator.
2. To diagnose the BCM function, select the menu of model and body control module.
3. To consult the present input/output value of BCM, "Current DATA". It provides information of BCM input/output conditions o power supply, turn signal/brake lamp, headlamp, door, locks, outside mirror, wiper, auto-light and transmitters etc. BCM Service data CLU (Cluster) Service data SJB(Smart junction box) Service data
4. To perform compulsory operation on BCM input factors, select "ACTUATION TEST".

Scheme 10

Scheme 11

Scheme 12

1. Disconnect the negative (-) battery terminal.
2. Remove the crash pad lower panel (A).
3. Remove the reinforce panel after loosening the mounting bolts.
4. Remove the duct (A) after removing the screw.
5. Remove the accelerator pedal module. (Refer to the " «ACCELERATOR PEDAL»(ref-675088-S30508932932014120400000) ")
6. Remove the body control module after loosening nut (1EA) and screw (1EA) and disconnecting the connectors (A).
