Heater & A/c Controller - Optima Hev: Removal & Installation Kia Optima III рестайлинг

Automatic HVAC System 8 illustrations ~143 words

Replacement

CAUTIONWhen prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Use a plastic panel removal tool to remove interior trim pieces to protect from marring the surface. Take care not to bend or scratch the trim and panels. Put on gloves to protect your hands.

Scheme 80

Scheme 80
Scheme 80

Scheme 81

Scheme 81
Scheme 81

Scheme 82

Scheme 82
Scheme 82

Scheme 83

Scheme 83
Scheme 83

Scheme 84

Scheme 84
Scheme 84

Scheme 85

Scheme 85
Scheme 85

Scheme 86

Scheme 86
Scheme 86

Scheme 87

Scheme 87
Scheme 87
  1. Using a screwdriver or remover, remove the crash pad side cover (A).
  2. After loosening the mounting screws, then remove the crash pad lower panel (A).
  3. Disconnect the crash pad lower switch connectors (A).
  4. Disconnect the diagnosis connector (B) and crash pad under lamp connector (C). [LH]
  5. Disconnect the start/stop button connector (D). [RH]
  6. Using a screwdriver or remover, remove the crash pad garnish [RH] (A).
  7. After loosening the mounting screws, then remove the heater control unit panel (A).
  8. Disconnect the connectors (A) and hose (B).
  9. After loosening the mounting screws, then remove the heater control unit (A).
  10. Installation is the reverse of removal. NOTE: Make sure the connector is plugged in properly. Replace any damaged clips.
