Warning systems — Chime circuit, except hybrid Kia Optima III
All systems — 40 systems
- Air conditioning 2.0l 2
- Air conditioning 2.4l 2
- Air conditioning 2.4l hybrid
- Anti-lock brakes 2
- Anti-theft 4
- Body control modules
- Computer data lines 2
- Cooling fan 2.0l
- Cooling fan 2.4l
- Cooling fan 2.4l hybrid
- Cruise control 2
- Defoggers 2
- Electronic power steering
- Engine performance 2.0l
- Engine performance 2.4l
- Engine performance 2.4l hybrid 3
- Exterior lights 4
- Ground distribution 2
- Headlights 3
- Horn 2
- Instrument cluster 2
- Interior lights 4
- Memory systems 2
- Navigation
- Power distribution 2
- Power door locks
- Power mirrors 3
- Power seats 4
- Power top/sunroof
- Power windows 3
- Radio 5
- Shift interlock 2
- Starting/charging 5
- Supplemental restraints
- Transmission 2.0l
- Transmission 2.4l
- Transmission 2.4l hybrid
- Trunk, tailgate, fuel door
- Warning systems 5
- Wiper/washer 2
Components on these wiring diagrams 27
Click a component to highlight it on every diagram it appears on.
