Tires/wheels/wheel Alignment - Except Hev: Specifications Kia Optima III

Wheel & Tire System 2 illustrations

Hub Nut Tightening Sequence

Tighten the hub nuts as follows.

Tightening torque

88.3 ~ 107.9 N.m (9.0 ~ 11.0kgf.m, 65.1 ~ 79.6 lb-ft)

Scheme 1

Scheme 1: Hub Nut Tightening Sequence
Scheme 1: Hub Nut Tightening Sequence
CAUTIONWhen using an impact gun, final tightening torque should be checked using a torque wrench.

Scheme 2

Scheme 2: Run Out Inspection
Scheme 2: Run Out Inspection
  1. Jack up the vehicle.
  2. Measure the wheel Run-out by using a dial indicator as illustration below. WHEEL RUN-OUT SPECIFICATION CHART Run-out Aluminum Steel Radial mm (in.) Below 0.3 (0.012) Below 1.4 (0.055) Lateral mm (in.) Below 0.3 (0.012) Below 0.9 (0.035)
  3. If measured value exceeds the standard value, replace the wheel.
