Front Suspension System - Except Hev: Overview Kia Optima III

Suspension Front 13 illustrations ~370 words

Scheme 1

Scheme 1: Components Location

Scheme 2

Scheme 2: Components

Scheme 3

Scheme 3: Replacement

Scheme 4

Scheme 4

Scheme 5

Scheme 5

Scheme 6

Scheme 6

Scheme 7

Scheme 7
  1. Remove the front wheel & tire. Tightening torque: 88.3 ~ 107.9 N.m (9.0 ~ 11.0kgf.m, 65.1 ~ 79.6 lb-ft) CAUTION: Be careful not to damage to the hub bolts when removing the front wheel & tire.
  2. Remove the wheel speed sensor (B) from the front strut assembly by loosening mounting bolts (A).
  3. Disconnect the stabilizer link (B) from the front strut assembly (A) after loosening the nut. Tightening torque: 98.1 ~ 117.7 N.m (10.0 ~ 12.0kgf.m, 72.3~86.8 lb-ft)
  4. Disconnect the front strut assembly (A) from the knuckle by loosening the bolt & nut. Tightening torque: 156.9 ~ 176.5 N.m (16.0 ~ 18.0kgf.m, 115.7 ~ 130.2 lb-ft)
  5. Remove the front strut assembly and then loosen the strut mounting nuts (A). Tightening torque: 53.9 ~ 68.6 N.m (5.5 ~ 7.0kgf.m, 39.8 ~ 50.6 lb-ft)
  6. Installation is the reverse of removal.

Scheme 8

Scheme 8: Disassembly
  1. Using the special tool (09546-26000), compress the coil spring (A). Tightening torque: 58.8 ~ 68.6 N.m (6.0 ~ 7.0kgf.m, 43.4 ~ 50.6 lb-ft)
  2. Remove the self-locking nut (C) from the strut assembly (B).
  3. Remove the insulator, spring seat, coil spring and dust cover from the strut assembly.
  4. Reassembly is the reverse of the disassembly.

Scheme 9

Scheme 9: Inspection
  1. Check the strut bearing for wear and damage.
  2. Check the spring upper and lower seat for damage and deterioration.
  3. Compress and extend the piston rod (A) and check that there is no abnormal resistance or unusual sound during operation.

Scheme 10

Scheme 10: Replacement

Scheme 11

Scheme 11

Scheme 12

Scheme 12

Scheme 13

Scheme 13
  1. Remove the front wheel & tire. Tightening torque: 88.3 ~ 107.9 N.m (9.0 ~ 11.0kgf.m, 65.1 ~ 79.6 lb-ft) CAUTION: Be careful not to damage to the hub bolts when removing the front wheel & tire.
  2. Loosen the bolt & nut and then remove the lower arm (A). Tightening torque: 98.1 ~ 117.7 N.m (10.0 ~ 12.0kgf.m, 72.3 ~ 86.6 lb-ft)
  3. Loosen the bolts and nuts and then remove the front lower arm (A). Tightening torque Front: 117.7 ~ 137.3 N.m (12.0 ~ 14.0kgf.m, 86.8 ~ 101.3 lb-ft) Rear: 137.3 ~ 156.9 N.m (14.0 ~ 16.0kgf.m, 101.3 ~ 115.7 lb-ft)
  4. Installation is the reverse of removal.
