Multifunction Switch - Except Hev: Diagnosis Kia Optima III

Steering Column Switches 16 illustrations ~296 words

Lighting Switch Inspection

With the multifunction switch in each position, make sure that continuity exists between the terminals below. If continuity is not as specified, replace the multi-function switch.

Scheme 3

Scheme 3: Lighting Switch Inspection

Scheme 4

Scheme 4: Lighting Switch (Auto Light)

Scheme 5

Scheme 5: Lighting Switch

Scheme 6

Scheme 6: Dimmer And Passing Switch

HU : Head lamp high beam

HL : Head lamp low beam

P : Head lamp passing switch

Scheme 7

Scheme 7: Turn Signal Switch

Scheme 8

Scheme 8: Front Fog Lamp Switch

Wiper And Washer Switch Inspection

With the multifunction switch in each position, make sure that continuity exists between the terminals below. If continuity is not as specified, replace the multi-function switch.

Scheme 9

Scheme 9: Wiper And Washer Switch Inspection

Scheme 10

Scheme 10: Wiper Switch

Scheme 11

Scheme 11: Washer Switch

Scheme 12

Scheme 12: Inspection (With GDS)

Scheme 13

Scheme 13
  1. Check BCM input/output specification of multifunction switch using the GDS. If the specification is abnormal, replace the lamp or wiper switch.
  2. If diagnosis is required on the multifunction switch, select model and "BCM".
  3. To consult the present input/output value of BCM, "Current DATA". It provides information of BCM input/output conditions of power supply, turn signal/brake lamp, headlamp, door, locks, outside mirror, wiper, auto-light and transmitters etc.
  4. To perform compulsory operation on BCM input factors, select "ACTUATION TEST".

Scheme 14

Scheme 14: Removal

Scheme 15

Scheme 15

Scheme 16

Scheme 16

Scheme 17

Scheme 17

Scheme 18

Scheme 18
  1. Disconnect the negative (-) battery terminal.
  2. Remove the steering wheel. Refer to «STEERING COLUMN & SHAFT»(ref-429546-S03884827802011101500000) .
  3. Remove the steering column upper and lower shrouds after removing 3 screws.
  4. If it is necessary to remove. The wiper & washer switch (A) only, release the lock of wiper switch using tool without removing the steering wheel and the clock spring.
  5. Disconnect the lighting switch connector (A) and wiper & washer switch connector (B).
  6. Remove the steering wheel. Refer to «STEERING COLUMN & SHAFT»(ref-429546-S03884827802011101500000) .
  7. Remove the clock spring. Refer to «AIRBAG MODULE»(ref-429545) .
  8. Remove the multifunction switch assembly (A) after loosening the mounting screws.
