Starting System - 2.4L: Diagnosis Kia Optima III

Starter Circuit Troubleshooting

Note. The battery must be in good condition and fully charged.

Scheme 60

1. Disconnect the fuel pump relay (A) in the fuse box.
2. With the shift lever in N or P (A/T) or clutch pedal pressed (M/T), turn the ignition switch to "START" If the starter normally cranks the engine, starting system is OK. If the starter will not crank the engine at all, go to next step. If it won't disengage from the ring gear when you release key, check for the following until you find the cause. Solenoid plunger and switch malfunction. Dirty pinion gear or damaged overrunning clutch.
3. Check the battery condition. Check electrical connections at the battery, battery negative cable connected to the body, engine ground cables, and the starter for looseness and corrosion. Then try starting the engine again. If the starter cranks normally the engine, repairing the loose connection repaired the problem. The starting system is now OK. If the starter still does not crank the engine, go to next step.
4. Disconnect the connector from the S-terminal of solenoid. Connect a jumper wire from the B-terminal of solenoid to the S-terminal of solenoid. If the starter cranks the engine, go to next step. If the starter still does not crank the engine, remove the starter, and repair or replace as necessary.
5. Check the following items in the order listed until you find the open circuit. Check the wire and connectors between the driver's under-dash fuse/relay box and the ignition switch, and between the driver's under-dash fuse/relay box and the starter. Check the ignition switch. Refer to «IGNITION SWITCH ASSEMBLY»(ref-429609) . Check the transaxle range switch (A/T), clutch pedal switch (M/T), ignition lock switch and their connections. Inspect the starter relay.

Scheme 61

Scheme 62

Scheme 63

1. Disconnect the field coil wire from the M-terminal of solenoid switch.
2. Connect the battery as shown. If the starter pinion pops out, it is working properly. To avoid damaging the starter, do not leave the battery connected for more than 10 seconds.
3. Disconnect the battery from the M terminal. If the pinion does not retract, the hold-in coil is working properly. To avoid damaging the starter, do not leave the battery connected for more than 10 seconds.
4. Disconnect the battery also from the body. If the pinion retracts immediately, it is working properly. To avoid damaging the starter, do not leave the battery connected for more than 10 seconds.

Scheme 64

1. Place the starter motor in a vise equipped with soft jaws and connect a fully-charged 12-volt battery to starter motor as follows.
2. Connect a test ammeter (150-ampere scale) and carbon pile rheostats as shown in the illustration.
3. Connect a voltmeter (15-volt scale) across starter motor.
4. Rotate carbon pile to the off position.
5. Connect the battery cable from battery's negative post to the starter motor body.
6. Adjust until battery voltage shown on the voltmeter reads 11.5 volts.
7. Confirm that the maximum amperage is within the specifications and that the starter motor turns smoothly and freely. Current : 105A, MAX Speed : 2, 950 RPM, MIN

Scheme 65

Scheme 66

Scheme 67

Scheme 68

1. Disconnect the battery negative terminal. Tightening torque: 4.0 ~ 6.0 N.m (0.4 ~ 0.6kgf.m, 3.0 ~ 4.4 lb-ft)
2. Remove the engine cover and the air cleaner assembly. Refer to «INTAKE MANIFOLD»(ref-429620-S13854361072011101500000) .
3. Remove the under cover. Refer to «REMOVAL»(ref-429618-S41710654112011101500000) .
4. Remove the ETC (Electronic throttle control) module (A) and MAPS (Manifold absolute pressure sensor & IATS (Intake air temperature sensor) (B). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
5. Remove the intake manifold stay (A). Tightening torque: 18.6 ~ 23.5 N.m (1.9 ~ 2.4 kgf.m, 13.7 ~ 17.4 lb-ft)
6. Disconnect the starter cable (A) from the B terminal on the solenoid, then disconnect the connector (B) from the S terminal.
7. Remove the 2 bolts (C) holding the starter, then remove the starter. Tightening torque: 42.2 ~ 53.9 N.m (4.3 ~ 5.5kgf.m, 31.1 ~ 39.8 lb-ft)
8. Installation is the reverse of removal.

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

Scheme 80

1. Disconnect the M-terminal (A) on the magnet switch assembly (B).
2. After loosening the screws (A), detach the magnet switch assembly (B).
3. Loosen the through bolts (A).
4. Remove the brush holder assembly (A), yoke (B) and armature (C).
5. Remove the lever plate (B) and lever packing (A).
6. Remove the packing (A) and shield (B).
7. Disconnect the planet gear (A).
8. Disconnect the planet shaft assembly (or reducer assembly) (A) and lever (B).
9. Press the stopper (A) using a socket (B).
10. After removing the stop ring (A) using stop ring pliers (B).
11. Disconnect the stopper (A), overrunning clutch (B), internal gear (C), planet shaft (or drive shaft) (D). NOTE: Using a suitable pulling tool (A), pull the overrunning clutch stopper (C) over the stop ring (B).
12. Reassembly is the reverse of disassembly.

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

1. Remove the starter.
2. Disassemble the starter as shown at the beginning of this procedure.
3. Inspect the armature for wear or damage from contact with the permanent magnet. If there is wear or damage, replace the armature.
4. Check the commutator (A) surface. If the surface is dirty or burnt, resurface with emery cloth or a lathe within the following specifications, or recondition with #500 or #600 sandpaper (B).
5. Measure the commutator (A) runout. If the commutator runout is within the service limit, check the commutator for carbon dust or brass chips between the segments. If the commutator run out is not within the service limit, replace the armature. Commutator runout Standard (New): 0.02 mm (0.0007 in.) max Service limit: 0.05 mm (0.0020 in.)
6. Check the mica depth (A). If the mica is too high (B), undercut the mica with a hacksaw blade to the proper depth. Cut away all the mica (C) between the commutator segments. The undercut should not be too shallow, too narrow, or shaped (D). Commutator mica depth Standard (New) : 0.7 ~ 0.9 mm (0.0276 ~ 0.0354 in) Limit : 0.4 mm (0.0157 in.)
7. Check for continuity between the segments of the commutator. If an open circuit exists between any segments, replace the armature.
8. Check with an ohmmeter that no continuity exists between the commutator (A) and armature coil core (B), and between the commutator and armature shaft (C). If continuity exists, replace the armature.

Inspect Starter Brush

Brushes that are worm out, or oil-soaked, should be replaced.

Scheme 87

Starter Brush Holder Test

Check that there is no continuity between the (+) brush holder (A) and (-) plate (B). If there is continuity, replace the brush holder assembly.

Scheme 88

Scheme 89

1. Slide the overrunning clutch along the shaft. Replace it if does not slide smoothly.
2. Rotate the overrunning clutch both ways. Does it lock in one direction and rotate smoothly in reverse? If it does not lock in either direction or it locks in both directions, replace it.
3. If the starter drive gear is worn or damaged, replace the overrunning clutch assembly. (the gear is not available separately). Check the condition of the flywheel or torque converter ring gear if the starter drive gear teeth are damaged.
