Auto Head Lamp Leveling Device - Except Hev: Diagnosis Kia Optima III

Headlights 11 illustrations ~315 words

Inspection With GDS

Initialization and diagnosis sequence by using GDS equipment.

Below content summarize the procedure for A/S using GDS.

No.Procedure
1Locate vehicle to flat plane
2Tire check
3IGN1 ON
4Head lamp Low Beam ON
5Connection with diagnostic tool
6Initial command by diagnostic tool
7Clear DTC Code
8IGN1 OFF --> ON
9Re-Connection with diagnostic tool
10Checking of HLLD output value as 15% and DTC Code
11HLLD actuating by diagnostic tool command
12Head lamp mechanical Initial Aiming

REPAIR PROCEDURES CHART

Note. There's no loads in vehicle and vehicle should be on flat plane. Should check of HLLD output value after initial setting. Should do first electrical initial setting by diagnostic tool and then mechanical aiming afterward.

Scheme 2

Scheme 2: Head Lamp Leveling
Scheme 2: Head Lamp Leveling

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9
  1. Select the vehicle model and "Head lamp leveling".
  2. GDS can operates actuator forcefully, input/output value monitoring and self diagnosis.
  3. To perform functional test on AHLS outputs, select "Actuation Test".
  4. Select "Parameter setting & Zero position Initial".
  5. Confirm that AHLS operate forcefully in "Head lamp leveling" menu.
  6. To check the DTC of the head lamp leveling system, select "Diagnostic trouble codes"

Scheme 10

Scheme 10: Replacement
Scheme 10: Replacement
  1. Disconnect the negative (-) battery terminal.
  2. Remove the head lamp assembly. Refer to «REMOVAL»(ref-429604-S21534416332011101500000) .
  3. Remove the head lamp leveling actuator (A) by loosening the adjusting bolt (B) after rotating it to an arrow direction.
  4. Installation is the reverse of removal procedure.

Scheme 11

Scheme 11: Circuit Diagram
Scheme 11: Circuit Diagram

Inspection

  1. Ignition "ON".
  2. Turn on the head lamp switch.
  3. Check for operation. If the aim of the head lamps changes smoothly when the head lamp leveling switch is turned.
  4. If the operation does not work well, inspect the connector and terminals to be sure they are all making good contact. If the terminals are bent, loose or corroded, repair them as necessary, and recheck the system. If the terminals look OK, go to step 5.
  5. Substitute with a known-good head lamp assembly and check for proper operation.

Scheme 12

Scheme 12: Removal
Scheme 12: Removal
  1. Remove the head lamp leveling unit connector (A).
  2. Loosen the mounting bolts (3 EA) of automatic head lamp leveling unit assembly. Tightening torque: 6.86±1.96 Nm (0.7±0.2 kgf.m, 5.06±1.44 lb.ft)
  3. Remove the head lamp leveling unit assembly.
