Power Windows: Diagnosis Kia Optima II рестайлинг

Inspection

1. Disconnect the negative (-) battery terminal.
2. Remove the junction box.
3. Check for continuity between the terminals.
4. There should be continuity between the No. 1 in the I/P-G and No. 12 terminal in the I/P-A when power and ground are connected to the No. 1 terminal in the I/P-G and No. 2 terminal in the I/P-A.
5. There should be no continuity between the No. 1 terminal in the I/P-G and No. 12 terminal in the I/P-A when power is disconnected.

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

1. No windows operate from the main switch on the driver's door.
2. Driver's side window does not operate.
3. Passenger's side window does not operate.

Scheme 7
