Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

1. Remove the engine cover (A).
2. Remove the RH front wheel.
3. Remove the RH side cover.
4. Set No. 1 cylinder to TDC/compression.
5. Drain the engine oil, and then set a jack to the oil pan. NOTE: Place wooden block between the jack and engine oil pan.
6. Disconnect the ground line and remove the engine mounting bracket (A).
7. Remove the drive belt (A).
8. Remove the idler (A) and drive belt tensioner (B). CAUTION: Tensioner pulley bolt is left - handed screw.
9. Remove the water pump pulley (A), crankshaft pulley (B) and engine support bracket (C). NOTE: Use the SST(flywheel stopper, 09231-3K000) to remove the crankshaft pulley bolt, after remove the starter
10. Disconnect the exhaust OCV connector (A).
11. Remove the breather hose (A).
12. Remove the PCV hose (A).
13. Disconnect the ignition coil connectors (A).
14. Remove the ignition coils (A).
15. Remove the cylinder head cover (A).
16. Remove the compressor lower bolts.
17. Remove the compressor bracket (A).
18. Remove the oil pan (A). CAUTION: Be careful not to damage the contact surfaces of cylinder block and oil pan.
19. Remove the timing chain cover (A) by prying the portions between the cylinder head and cylinder block with a screwdriver. CAUTION: Be careful not to damage the contact surfaces of cylinder block, cylinder head and timing chain cover.
20. The key of crankshaft should be aligned with the mating face of main bearing cap. As a result of this, the piston of No. 1 cylinder is placed at the top dead center on compression stroke.
21. Install a set pin after compressing the timing chain tensioner.
22. Remove the timing chain tensioner (A) and timing chain tensioner arm (B).
23. Remove the timing chain.
24. Remove the timing chain guide (A).
25. Remove the timing chain oil jet (A).
26. Remove the crankshaft chain sprocket (B).
27. Remove the balance shaft chain.

(Refer to LUBRICATION SYSTEM - 2.4L in this group)
