Service Standards

Standard value
AntifreezeMixture ratio of anti-freeze in coolant
ETHYLENE GLYCOL BASE FOR ALUMINUM50%

STANDARD VALUE REFERENCE

Compression

Note. If the there is lack of power, excessive oil consumption or poor fuel economy, measure the compression pressure.

Scheme 15

Scheme 15: Compression

Scheme 16

Scheme 16

Scheme 17

Scheme 17
  1. Warm up and stop engine. Allow the engine to warm up to normal operating temperature.
  2. Disconnect the injector connectors (A) and ignition coil connectors (B).
  3. Remove ignition coils(A).
  4. Remove spark plugs. Using a 16mm plug wrench, remove the 4 spark plugs.
  5. Check cylinder compression pressure. Insert a compression gauge into the spark plug hole. Fully open the throttle. While cranking the engine, measure the compression pressure. NOTE: Always use a fully charged battery to obtain engine speed of 200 rpm or more. Repeat steps (a) through (c) for each cylinder. NOTE: This measurement must be done in as short a time as possible. Compression pressure : 1,283kPa (13.0kgf/cm 2 , 185psi) Minimum pressure : 1,135kPa (11.5kgf/cm 2 , 164psi) Difference between each cylinder : 100kPa (1.0kgf/cm 2 , 15psi) or less If the cylinder compression in 1 or more cylinders is low, pour a small amount of engine oil into the cylinder through the spark plug hole and repeat steps (a) through (c) for cylinders with low compression. If adding oil helps the compression, it is likely that the piston rings and/or cylinder bore are worn or damaged. If pressure stays low, a valve may be sticking or seating is improper, or there may be leakage past the gasket.
  6. Reinstall spark plugs.
  7. Install ignition coils.
  8. Connect the injector connectors and ignition coil connectors.

Special Service Tools

SPECIAL SERVICE TOOLS REFERENCE Tool (Number and name) Illustration Use Crankshaft front oil seal installer (09214-3K000) (09231-H1100) Installation of the front oil seal 09214-3K000 09231-H1100 Flywheel stopper (09231-3K000) Removal and installation of the flywheel and crankshaft pulley. Torque angle adapter (09221-4A000) Installation of bolts & nuts needing an angular method Valve stem oil seal installer (09222-4A000) Installation of the valve stem oil seal Valve spring compressor & holder (09222-3K000) (09222-3K100) Removal and installation of the intake or exhaust valve 09222-3K100 (holder) Crankshaft rear oil seal installer (09214-3K100) (09231-H1100) Installation of the crankshaft rear oil seal 09214-3K100 09231-H1100 Timing chain tensioner ratchet holder (09240-2G000) Timing chain tension release

Scheme 18

Scheme 18: Special Service Tools

Scheme 19

Scheme 19

Scheme 20

Scheme 20

Scheme 21
