1. Drain engine oil.
2. Remove the front right wheel and tire.
3. Remove the front right side cover.
4. Remove the front muffler.
5. Remove the generator.
6. Remove the timing belt.
7. Remove the oil filter bracket (A).
8. Using SST (09215-3C000), remove the lower oil pan (A). CAUTION: Be careful not to damage the contact surfaces of upper oil pan and lower oil pan.
9. Remove the oil screen (A).
10. Remove the upper oil pan, using the SST (09215-3C000) (A). CAUTION: Be careful not to damage the contact surfaces of upper oil pan and lower oil pan.
11. Remove the oil pump case (A).
12. After removing the plug (C), remove the relief spring (B) and the relief plunger (A).
