Power Relay Test (Type A)

Check for continuity between the terminals.

1. There should be continuity between the No. 30 and No. 87 terminals when power and ground are connected to the No. 85 and No. 86 terminals.
2. There should be no continuity between the No. 30 and No. 87 terminals when power is disconnected.

Scheme 5

Scheme 6

Power Relay Test (Type B)

Check for continuity between the terminals.

1. There should be continuity between the No. 30 and No. 87 terminals when power and ground are connected to the No. 85 and No. 86 terminals.
2. There should be continuity between the No. 30 and No. 87a terminals when power is disconnected.

Scheme 7

Scheme 8

Power Relay Test (Type C)

Check for continuity between the terminals.

1. There should be continuity between the No. 30 and No. 87 terminals when power and ground are connected to the No. 85 and No. 86 terminals.
2. There should be no continuity between the No. 30 and No. 87 terminals when power is disconnected.

Scheme 9

Scheme 10

Power Relay Test (Type D)

Check for continuity between the terminals.

1. There should be continuity between the No. 30 and No. 87 terminals when power and ground are connected to the No. 85 and No. 86 terminals.
2. There should be continuity between the No. 30 and No. 87 terminals when power is disconnected.

Scheme 11

Scheme 12

Fuse Inspection

1. Be sure there is no play in the fuse holders, and that the fuses are held securely.
2. Are the fuse capacities for each circuit correct?
3. Are there any blown fuses? If a fuse is to be replaced, be sure to use a new fuse of the same capacity. Always determine why the fuse blew first and completely eliminate the problem before installing a new fuse.

Scheme 13

1. Be sure there is no play in the fuse holders, and that the fuses are held securely.
2. Are the fuse capacities for each circuit correct?
3. Are there any blown fuses? If a fuse is to be replaced, be sure to use a new fuse of the same capacity. Always determine why the fuse blew first and completely eliminate the problem before installing a new fuse.
