Lighting System: Removal & Installation Kia Optima II рестайлинг

Installation

1. Install the head lamp assembly after connecting the connector.
2. Install the radiator under cover.
3. Connect the negative (-) battery terminal.

Scheme 17

Scheme 18

Scheme 19

1. Disconnect the negative (-) battery terminal.
2. Remove the trim cover (A).
3. Remove the rear combination lamp (Outside) fixing nuts (4EA).
4. Remove the outside rear combination lamp (A) and connector (B).
5. Replace the bulbs (A). (Replace the lamp assembly when the LED is out of order)

Scheme 20

Scheme 21

Scheme 22

1. Disconnect the negative (-) battery terminal.
2. Loose the nuts holding the rear combination inside lamp (A).
3. Remove the connector (B) and rear combination inside lamp (A).
4. Replace the bulbs (A). (Replace the lamp assembly when the LED is out of order)

Scheme 23

1. Install the rear combination outside lamp assembly.
2. Install the rear combination inside lamp assembly.

Scheme 24

Scheme 25

1. Disconnect the negative (-) battery terminal.
2. Detach the lamp lens (A) from the room lamp with a flat-tip screwdriver then replace the bulb.
3. Remove the room lamp assembly after removing 2 bolts and disconnecting the 4P connector (Standard type). Remove the room lamp assembly (A) by using the scraper and then disconnect the 4P connector (Sunroof type).

1. Connect the connector and install the room lamp.
2. Install the lamp lens.

1. Install the overhead console lamp after connecting the sunroof switch connector and lamp connector.
2. Install the lens after tightening 2 screws.

1. Install the bulb.
2. Install the license lamp lens.

Removal

1. Disconnect the negative(-) battery terminal.
2. Open the trunk lid and then disconnect the connector of high mounted stop lamp.
3. Remove the package tray (Refer to the «PACKAGE TRAY»(ref-357465-S22579042832010032300000) ).
4. Replace the bulb(A) from the package tray.

Scheme 26

1. Install the high mounted stop lamp to the rear package tray.
2. Install the rear package tray.

Scheme 27

1. Disconnect the negative (-) battery terminal.
2. Open the trunk lid, then remove the trunk room lamp (A) with a flat-tip screwdriver and disconnect the 2P connector (B).
3. Replace the bulb.

1. Install the bulb.
2. Install the trunk lamp lens.
