Specifications
| Items | Specifications | |
|---|---|---|
| Rated voltage | DC 12V | |
| Operating voltage | DC 9 ~ 16V | |
| Operating temperature | 22°F~176°F(-30°C~ 80°C) | |
| Insulation resistance | 100Mohms or more | |
| Dark current | Less than 8mA (12.8 V) - BCM & Receiver Less than 4mA (12.8V) - BCM | |
| Rated load | Burglar relay | DC 12V, 200mA (Inductance load) |
| Horn relay | DC 12V, 200mA (Inductance load) | |
| Tail lamp relay | DC 12V, 200mA (Inductance load) | |
| Head lamp relay | DC 12V, 200mA (Inductance load) | |
| Rear defogger relay | DC 12V, 200mA (Inductance load) | |
| Power window timer relay | DC 12V, 200mA (Inductance load) | |
| Seat belt warning indicator (Driver/Assist) | DC 12V, 1.2W (LED load) | |
| Key hole illumination lamp | DC 12V, 2W (Lamp load) | |
| Room lamp | DC 12V, 20W (Lamp load) | |
| Intermittent wiper relay | DC 12V, 200mA (Inductance load) | |
| DRL relay | DC 12V, 200mA (Inductance load) | |
| Door lock relay | DC 12V, 200mA (Inductance load) | |
| Door unlock relay | DC 12V, 200mA (Inductance load) | |
| Hazard lamp relay | DC 12V, 200mA (Inductance load) | |
| Driver door unlock relay | DC 12V, 200mA (Inductance load) | |
| Trunk lid lock actuator | DC 12V, 200mA (Inductance load) | |
| Rear fog relay | DC 12V, 200mA (Inductance load) | |
BODY CONTROL MODULE SPECIFICATIONS
Scheme 1
Scheme 2
| Pin No. | Connector A | Connector B | Connector C | Connector D |
|---|---|---|---|---|
| 1 | B+ | Driver door key lock switch | Auto light switch | Room/Foot lamp |
| 2 | IGN 1 | Assist door key unlock switch | Front deicer switch | Power window relay |
| 3 | Stop lamp switch | Trunk key unlock switch | Auto light GND | Lock relay |
| 4 | "D" Inhibit switch | Tail switch | Wiper INT volume switch | DRL |
| 5 | ALT L | Pin code | CAN hi | Key hole illumination |
| 6 | Key in switch | AV tail | Key solenoid | Tail lamp relay |
| 7 | Washer switch | Key inter lock switch | Hazard relay | Trunk relay |
| 8 | Assist door switch | Rear fog switch | Head lamp relay | Head lamp relay |
| 9 | Assist door unlock switch | Head lamp switch | Rear defogger switch | |
| 10 | Rear door unlock switch LH | Driver door key unlock switch | Auto light signal | Driver seat belt indicator |
| 11 | Power window door lock switch | Trunk open switch | Auto light power | Security indicator |
| 12 | IGN 2 | Speed sensor | START Inhibit relay | |
| 13 | ACC | Hood switch | PAB signal | Unlock relay |
| 14 | "P" Inhibit switch | Trunk release switch | Hi scan | Door unlock relay dead lock |
| 15 | "N" Inhibit switch | Dead lock pin code | CAN low | |
| 16 | GND | Defogger relay | ||
| 17 | MIST switch | TX Unlock (AV) | ATM solenoid | Rear fog relay |
| 18 | INT switch | Crush input | GND (power) | Front deicer relay |
| 19 | Code save unit | Seat belt switch | Horn relay | |
| 20 | Driver door switch | Front fog switch | ||
| 21 | Driver door unlock switch | |||
| 22 | 4 door switch | Assist seat belt indicator | ||
| 23 | Rear door unlock switch RH | |||
| 24 | Power window door unlock switch |
