Engine Control System (Fuel System (G6EA - Gsl 2.7L)): Specifications Kia Optima II

SPECIFICATION

FREQUENCY SPECIFICATION CHART

Scheme 31

RESISTANCE SPECIFICATION

Scheme 32

1. Turn ignition switch OFF.
2. Disconnect IATS connector.
3. Measure resistance between IATS terminals 4 and 5.
4. Check that the resistance is within the specification. Specification: Refer to «SPECIFICATION»(ref-266013-S16319809012007092700000) .

Scheme 33

Manifold Absolute Pressure Sensor (MAPS) is speed-density type sensor and is installed on the surge tank. This MAPS senses absolute pressure in surge tank and transfers this analog signal proportional to the pressure to the PCM. The PCM calculates the intake air quantity and engine speed based on this signal. This MAPS consists of piezoelectric element and hybrid IC that amplifies the element output signal. The element is silicon diaphragm type and adapts pressure sensitive variable resistor effect of semi-conductor. 100% vacuum and the manifold pressure applies to both sides of it respectively. That is, this sensor outputs the silicon variation proportional to pressure change by voltage.

VOLTAGE OUTPUT CHART

Scheme 34

RESISTANCE SPECIFICATION

Scheme 35

Scheme 36

1. Turn ignition switch OFF.
2. Disconnect ECTS connector.
3. Remove the ECTS.
4. After immersing the thermistor of the sensor into engine coolant, measure resistance between ECTS terminals 1 and 3.
5. Check that the resistance is within the specification. Specification: Refer to «SPECIFICATION»(ref-266013-S25334242492007092700000) .

VOLTAGE OUTPUT CHART

HEATER RESISTANCE SPECIFICATION

Scheme 37

Scheme 38

Scheme 39

1. Check signal waveform of HO2S using a scan tool. Specification: Refer to " «WAVEFORM»(ref-266013-S35528494092007092700000) ".
2. Disconnect the HO2S connector.
3. Measure resistance between HO2S heater terminals 3 and 4.
4. Check that the resistance is within the specification. Specification: Refer to «SPECIFICATION»(ref-266013-S30312348932007092700000) .

ITEM SPECIFICATION

Scheme 40

Scheme 41

COIL RESISTANCE SPECIFICATION

Scheme 42

Scheme 43

1. Turn ignition switch OFF.
2. Disconnect injector connector.
3. Measure resistance between injector terminals 1 and 2.
4. Check that the resistance is within the specification. Specification: Refer to «SPECIFICATION»(ref-266013-S33104931372007092700000) .

COIL RESISTANCE SPECIFICATION

Scheme 44

Scheme 45

1. Turn ignition switch OFF.
2. Disconnect OCV connector.
3. Measure resistance between OCV terminals 1 and 2.
4. Check that the resistance is within the specification. Specification: Refer to «SPECIFICATION»(ref-266013-S42422119142007092700000) .

RESISTANCE SPECIFICATION

Scheme 46

Scheme 47

1. Turn ignition switch OFF.
2. Disconnect OTS connector.
3. Remove the OTS.
4. After immersing the thermistor of the sensor into water (or engine coolant), measure resistance between OTS terminals 1 and 2.
5. Check that the resistance is within the specification. Specification: Refer to «SPECIFICATION»(ref-266013-S12906311682007092700000) .

COIL RESISTANCE SPECIFICATION

Scheme 48

Scheme 49

1. Turn ignition switch OFF.
2. Disconnect PCSV connector.
3. Measure resistance between PCSV terminals 1 and 2.
4. Check that the resistance is within the specification. Specification: Refer to «SPECIFICATION»(ref-266013-S14137920662007092700000) .

COIL RESISTANCE SPECIFICATION

Scheme 50

Scheme 51

1. Turn ignition switch OFF.
2. Disconnect VIS Valve connector.
3. Measure resistance between VIS Valve #1 and # 2 terminals 1 and 2.
4. Check that the resistance is within the specification. Specification: Refer to «SPECIFICATION»(ref-266013-S01460851662007092700000) .

Scheme 52

Accelerator Position Sensor (APS) is installed on the accelerator pedal module and detects the rotation angle of the accelerator pedal. The APS is one of the most important sensors in engine control system, so it consists of the two sensors which adapt individual sensor power and ground line. The second sensor monitors the first sensor and its output voltage is half of the first one. If the ratio of the sensor 1 and 2 is out of the range (approximately 1/2), the diagnostic system judges that a malfunction has occurred.

VOLTAGE OUTPUT SPECIFICATION

SENSOR RESISTANCE SPECIFICATION

Scheme 53

Scheme 54

1. Connect a scan tool on Diagnosis Link Connector (DLC).
2. Start engine and check output voltages of APS 1 and 2 at C.T. and W.O.T. SPECIFICATION VOLTAGE OUTPUT SPECIFICATION Condition Output Voltage (V) APS1 APS2 C.T. 0.70-0.80 0.29-0.46 W.O.T. 3.85-4.35 1.93-2.18
3. Turn ignition switch OFF and disconnect the scan tool from the DLC.
4. Disconnect APS connector and measure resistance between APS terminals 4 and 5 (APS 1). Specification: Refer to «SPECIFICATION»(ref-266013-S11504816792007092700000) .
5. Disconnect APS connector and measure resistance between APS terminals 1 and 6 (APS 2). Specification: Refer to «SPECIFICATION»(ref-266013-S11504816792007092700000) .

Scheme 55

The evaporative emission control system prevents hydrocarbon vapors from escaping from the fuel tank into the atmosphere where they could form photochemical smog. Gasoline vapors are collected in the charcoal canister. The Fuel Tank Pressure Sensor (FTPS) is installed on fuel pump assembly and is an integral part of the evaporative monitoring system. The PCM monitors the FTPS signal to detect vacuum decay and excess vacuum. The FTPS measures the difference between the air pressure inside the fuel tank and outside air pressure to check the purge control solenoid valve operation and for leak detection in the evaporative emission control system by monitoring pressure and vacuum levels in the fuel tank during the purge control solenoid valve operating cycles.

VOLTAGE OUTPUT SPECIFICATION

Scheme 56

COIL RESISTANCE SPECIFICATION

Scheme 57

Scheme 58
