Auto Lighting Control System: Specifications Kia Optima II

Headlights 2 illustrations

SPECIFICATIONS

Items		Specifications
Rated voltage		5V
Load		Max. 1mA
Detection illuminations	Tail lamp	ON: 24 +/- 5.2 (Lux), 0.81 +/- 0.08 (V) OFF: 48 +/- 0.5 (Lux), 1.41 +/- 0.10 (V)
Detection illuminations	Head lamp	ON: 24 +/- 5.2 (Lux), 0.81 +/- 0.08 (V) OFF: 48 +/- 0.5 (Lux), 1.41 +/- 0.10 (V)

VOLTAGE SPECIFICATIONS

Scheme 1

Scheme 1: CIRCUIT DIAGRAM

Scheme 1: CIRCUIT DIAGRAM

Scheme 2

Scheme 2: COMPONENT LOCATION

Scheme 2: COMPONENT LOCATION
