HEAD LAMP AIMING INSTRUCTIONS
The head lamps should be aimed with the proper beam-setting equipment, and in accordance with the equipment manufacturer's instructions.
Note. If there are any regulations pertinent to the aiming of head lamps in the area where the vehicle is to be used, adjust so as to meet those requirements.
Alternately turn the adjusting gear to adjust the head lamp aiming. If beam-setting equipment is not available, proceed as follows
Scheme 24
- Inflate the tires to the specified pressure and remove any loads from the vehicle except the driver, spare tire, and tools.
- The vehicle should be placed on a flat floor.
- Draw vertical lines (Vertical lines passing through respective head lamp centers) on the screen.
- With the head lamp and battery in normal condition, aim the head lamps so the brightest portion falls on the vertical lines. Make vertical adjustments to the lower beam using the adjusting wheel.
FRONT FOG LAMP AIMING
The front fog lamps should be aimed as the same manner of the head lamps aiming.
With the front fog lamps and battery normal condition, aim the front fog lamps by turning the adjusting gear (A).
Scheme 25
Scheme 26
| Vehicle condition | H1 | H2 | H2 | W1 | W2 | W3 | L |
|---|---|---|---|---|---|---|---|
| Without driver | 29.1(739) | 29.6(684) | 14.4(363) | 56.8(1,442) | 47.7(1,211) | 50.0(1,269) | 118.1(3,000) |
| With driver | 28.7(730) | 26.8(680) | 13.9(354) |
VEHICLE CONDITION
Scheme 27
Scheme 28
- Turn the low beam on without driver aboard. The cut-off line should be projected in the allowable range (shaded region). If head lamp leveling device is equipped, adjust the head lamp leveling device switch with 0 positions.
- Turn the front fog lamp on without the driver aboard. The cut-off line should be projected in the allowable range (shaded region)
Scheme 29
Scheme 30
- Disconnect the negative (-) battery terminal.
- Loose the nuts holding the rear combination lamp then disconnect the 4P connector then remove the outside rear combination lamp.
- Loose the nuts holding the rear combination lamp then disconnect the 4P connector then remove the inner rear combination lamp.
- Installation is the reverse of removal.
Scheme 31
Scheme 32
- Disconnect the negative (-) battery terminal.
- Detach the lamp lens (A) from the room lamp with a flat-tip screwdriver then replace the bulb.
- Remove the room lamp assembly after removing 2 bolts and disconnecting the 4P connector (Standard type). Remove the room lamp assembly (A) by using the scraper and then disconnect the 4P connector (Sunroof type).
- Installation is the reverse of removal.
