Wiring diagram: Radio — Radio circuit, without amplifier Kia Optima I facelift
All systems — 35 systems
- Air conditioning 2.4l 2
- Air conditioning 2.7l 2
- Anti-lock brakes
- Anti-theft
- Body control modules
- Computer data lines 2.4l
- Computer data lines 2.7l
- Cooling fan
- Cruise control
- Defoggers
- Electronic power steering
- Engine performance 2.4l 2
- Engine performance 2.7l
- Exterior lights 2
- Ground distribution
- Headlights 3
- Horn
- Instrument cluster
- Interior lights 3
- Power antenna
- Power distribution
- Power door locks
- Power mirrors
- Power seats 3
- Power top/sunroof
- Power windows
- Radio 2
- Starting/charging 2
- Starting/charging 2.4l
- Supplemental restraints
- Transmission 2.4l
- Transmission 2.7l
- Trunk, tailgate, fuel door
- Warning systems
- Wiper/washer
Components on these wiring diagrams 10
Click a component to highlight it on every diagram it appears on.
