Scheme 1
Scheme 2
DESCRIPTION
Vehicle door is attached to vehicle body by two hinges and a door checker. Door checker limits amount of swing of the vehicle door. A hollow rubber weatherstrip is installed on the door opening flange to prevents leaks between vehicle door and inside of vehicle body. The door lock assembly is linked with outside and inside door handle. The power window system is comprised of a window regulator assembly (on which glass is fastened), a front glass guide (which guides movement of glass at front side) and a window power switch (switch for up and down movement of glass, which is attached to armrest). A plastic door screen covers door frame, protecting all components. The door striker may be adjusted for proper operation and easy door closure.
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
- Disconnect negative battery cable.
- Remove door garnish. Unfasten garnish. Disconnect electrical connector.
- Remove inside handle cover. Remove one screw. Unfasten inside handle cover.
- Remove door trim. Remove one screw from pull handle. Remove two screws from right side of door trim. Remove two screws and cover from left side of door trim. Remove two screws from bottom of door trim. Unfasten door trim. Disconnect electrical connector.
- Remove inside door handle assembly. Disconnect two remote control rods from door lock assembly. Remove two screws from inside door handle.
- Remove two screws from pull handle bracket.
- Peel off plastic door screen carefully by pulling it away gradually from door frame. NOTE: Peel plastic moisture barrier off carefully so that it can be reused.
- Remove window glass. Reconnect window operating switch. Connect negative battery cable. Turn ignition "ON" and position window glass about halfway. Turn ignition "OFF". Remove glass run channel. Remove two glass mounting bolts from window regulator assembly. Remove glass carefully; hold glass from both its inner and outer surfaces. While tilting it toward hinge side of door, pull it out from outside door frame. Disconnect negative battery cable.
- Remove regulator assembly. Disconnect window regulator motor connector. Remove seven nuts from door frame. Remove window regulator assembly from out of access hole.
Scheme 12
Scheme 13
Scheme 14
Scheme 15
Scheme 16
Scheme 17
Scheme 18
Scheme 19
- Install regulator assembly. Position regulator assembly through access hole. Install seven mounting nuts. Connect electrical connector for motor of regulator assembly.
- Install window glass. Position glass carefully: Hold glass from both its inner and outer surfaces. While tilting it towards hinge side of door, place it on small bracket on window regulator assembly. Loosely install two glass mounting bolts on window regulator assembly. Reconnect window operating switch. Connect negative battery cable. Turn "ON" ignition and move glass up and down to ensure proper function. Make adjustments as necessary. Turn "OFF" ignition. Disconnect window operating switch. Disconnect negative battery cable. Tighten two glass mounting bolts on power window regulator assembly. Tighten two bolts to 8~12 N.m (80~120 kg-cm, 69~104 lb-in)
- Install run channel. Use soap and water for lubrication.
- Install plastic door screen. Fasten plastic door screen. Pull out electrical harness connector from plastic door screen. Pull out remote control rod for inside door handle from plastic door screen.
- Install pull handle bracket with two mounting screws.
- Install inside door handle assembly. Install two mounting screws. Connect two remote control rods of door lock assembly.
- Install door trim. Connect electrical connector. Place front door trim. Install two screws on bottom of door trim. Install two screws and cover on left side of door trim. Install two screws on right side of door trim. Install one screw on pull handle bracket.
- Install inside handle cover. Fasten inside handle cover. Install one screw and cover.
- Install door garnish.
- Connect negative battery cable.
