TIGHTENING TORQUE
| WARNING | Always follow torque tightening levels. Failure to follow such levels can result in parts breaking if over tightened or loosening if under-tightened. In either case, serious personal injury or death could result to the vehicle occupants. |
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
- Remove the wheel and tire.
- Detach the brake hose from the fork.
- Remove the bolt from the shock absorber bushing.
- Remove the bolt then remove the fork from the shock absorber.
- Remove the strut upper mounting 3 nuts and top mounting ring.
- While pushing the axle assembly upward, remove the strut assembly.
Scheme 10
- Using the special tool, spring compressor, compress the coil spring.
- Remove the self-locking nut.
- Remove the special tool, bracket, spring pad and coil spring.
