Audio System: Overview Kia Optima I рестайлинг

Scheme 1

Scheme 2

Scheme 3

1. Disconnect the negative (-) battery terminal.
2. Remove the center facia panel and disconnect the wire connectors.
3. Remove the 4 screws holding the audio unit, then remove the audio assembly.
4. Disconnect the power connector and antenna cable jack from the audio unit.
5. Installation is the reverse of removal.

Scheme 4

1. To obtain optimum performance, clean the head and capstan as often as necessary, depending upon frequency of use and tape cleanness.
2. To clean the tape head and capstan, use a cotton swab dipped in ordinary rubbing alcohol. Wipe the head and capstan.

DESCRIPTION AND OPERATION

The antenna is an intergral part of the AM/FM radio. The antenna is mounted to left rear fender and receives AM and FM signals which are sent through antenna cable to the radio.
