Cruise Control System: Overview Kia Optima I

Locating Actuator & Unit Assembly. Scheme 1

Locating Clutch Switch. Scheme 2

Locating SET/RESUME Switch. Scheme 3

Locating Cruise Main Switch. Scheme 4

Locating Stop Lamp Switch. Scheme 5

Vehicle Speed Sensor. Scheme 6

Scheme 7

Scheme 8

1. Remove the battery negative terminal.
2. Disconnect the accelerator cable and cruise control cable from throttle assembly by turning the throttle lever to the full open position.
3. Disconnect the accelerator cable from accelerator pedal connection.
4. Remove the accelerator cable mounting bolts. (Scheme 7): Removing Accelerator Cable Mounting Bolts
5. Remove the actuator and unit assembly mounting bolt. (Scheme 8): Removing Actuator & Unit Assembly Mounting Bolt
6. Installation is the reverse order of removal.
