Body control modules — Body control module circuit Kia Niro I

Components on these wiring diagrams 47

Click a component to highlight it on every diagram it appears on.

• Auto Light Sensor Gnd
• Auto Light Sensor Pwr
• Auto Light Sensor Sig
• B-Can High
• B-Can Low
• Blade Pos Sw In
• C-Can High
• C-Can Low
• Crash O/P
• Door Locks, Anti-Theft Systems
• Fog Lamp Sw In
• Folding Rly Ctrl
• Front Washer Sig
• Headlamp High Sw In
• Heated Handle Pwr 1
• Heated Handle Pwr 2
• Heated Handle Sw Ind
• Heated Handle Sw Sig
• I/P-E
• I/P-F
• Int/Vol Sw
• Key In Sw
• Key Interlock Sw
• Key Lock Solenoid
• Leak Current Auto Cut Device
• Light Sw Sig
• Memory 1 Fuse
• Module 2 Fuse
• Module 3 Fuse
• Module 6 Fuse
• Pas Sw Mode
• Pocket Lamp
• Rear Defogger Sw I/P
• Rear Washer Sw Sig
• Room Lamp O/P
• Safety Pwr Window Enable
• Security Ind
• Shift Lock Solenoid
• Steering Wheel Heated Ntc
• Steering Wheel Heated Pwr
• Stop Lamp Sw
• Sunroof Enable High
• Sunroof Open Sw I/P
• Unfolding Rly Ctrl
• Warning Systems
• Wiper Backup Sw Sig
• Wiper Sw Sig
