Wiring diagram: Shift interlock — Shift interlock circuit, except hybrid w/ dct Kia K5 II
All systems — 52 systems
- Air conditioning 3
- Anti-lock brakes 3
- Anti-theft 5
- Body control modules 1.6l turbo 2
- Body control modules 2.0l hybrid 2
- Body control modules 2.0l plug-in hybrid 2
- Body control modules 2.0l turbo 2
- Body control modules 2.4l 2
- Computer data lines 2
- Cooling fan 2
- Cruise control 2
- Defoggers 3
- Electronic power steering 3
- Engine performance 1.6l turbo
- Engine performance 2.0l hybrid 3
- Engine performance 2.0l plug-in hybrid 3
- Engine performance 2.0l turbo
- Engine performance 2.4l
- Exterior lights 4
- Ground distribution 1.6l turbo
- Ground distribution 2.0l hybrid
- Ground distribution 2.0l plug-in hybrid
- Ground distribution 2.0l turbo
- Ground distribution 2.4l
- Headlights 8
- Horn
- Instrument cluster 2
- Interior lights 4
- Memory systems 2
- Navigation 10
- Power distribution 1.6l turbo
- Power distribution 2.0l hybrid
- Power distribution 2.0l plug-in hybrid
- Power distribution 2.0l turbo
- Power distribution 2.4l
- Power door locks 2
- Power mirrors 5
- Power seats 10
- Power top/sunroof 2
- Power windows 6
- Radio 11
- Shift interlock 4
- Starting/charging 3
- Supplemental restraints 2
- Transmission 1.6l turbo
- Transmission 2.0l hybrid
- Transmission 2.0l plug-in hybrid
- Transmission 2.0l turbo
- Transmission 2.4l
- Trunk, tailgate, fuel door 2
- Warning systems 4
- Wiper/washer 2
Components on these wiring diagrams 30
Click a component to highlight it on every diagram it appears on.
