Kia K5 II (2015-2020) brn Wiring diagrams

This page contains all the electrical diagrams for the component. brn, in which he is found in the car Kia K5 II (2015-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

brn wiring diagram (41 of 280)

BLK WIRE BRN WIRE C-CAN CENTER PERSONAL LAMP CENTER ROOM LAMP CLUSTER FUSE COMPUTER DATA LINES SYSTEM DOOR I/P-D IGPM ILL INSTRUMENT CLUSTER INSTRUMENT ILLUMINATION CIRCUIT LEFT FRONT VANITY LAMP LEFT FRONT VANITY LAMP SWITCH LEFT MAP LAMP LEFT REAR PERSONAL LAMP MICOM OFF OVERHEAD CONSOLE LAMP RED WIRE REG RELAY ENERGIZED RIGHT FRONT VANITY LAMP RIGHT FRONT VANITY LAMP SWITCH RIGHT MAP LAMP RIGHT REAR PERSONAL LAMP ROOM SIG 1 GND TRANSCEIVER/ W/ SUNROOF W/O SUNROOF W/ CENTER ROOM LAMP W/O CENTER ROOM LAMP WHT WIRE YEL WIRE YEL/BLK WIRE

Go to component -> Courtesy lamps circuit, hybrid (2 of 2) -> BRN WIRE

brn wiring diagram (42 of 280)

2.0L TURBO 2.4L ANTENNA COIL BLK WIRE BLU WIRE BRAKE SWITCH FUSE BRN WIRE C-CAN COIL COMPUTER DATA LINES SYSTEM ECM (1.6L TURBO) PCM (2.4L, 2.0L TURBO) EMS GRN WIRE GROUND GRY WIRE HOT AT ALL TIMES HOT IN ON OR START I/P-D I/P-E IGNITION KEY ILLUMINATION, DOOR WARNING SWITCH IMMO IMMO DATA LINE IMMO IND IMMOBILIZER MODULE (UPPER LEFT SIDE OF DASH) IND INPUT SIG INTERFACE INSTRUMENT CLUSTER K LINE K-LINE SIG INTERFACE LEAK CURRENT AUTO CUT DEVICE MEM PWR MEMORY 1 FUSE MICOM MICRO CONTROLLER MODULE 9 FUSE NCA WIRE ON/ST INPUT ORG/ WIRE PNK WIRE PWR SUPPLY REGULATION SERIAL SIG INTERFACE SMART JUNCTION BLOCK TRANSCEIVER/ TRANSPONDER TRANSPONDER READER IC WHT WIRE WHT/ORG WIRE

Go to component -> Immobilizer circuit, except hybrid w/o smart key system -> BRN WIRE

brn wiring diagram (43 of 280)

2.0L TURBO 2.4L ACC/ON INPUT ATM SHIFT LEVER B-CAN HIGH B-CAN LOW BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BRK SW SIG BRN WIRE C-CAN HIGH C-CAN LOW COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM DRIV DR LCK/UNLCK SW DRIVER SMART KEY OUTSIDE HANDLE (INTEGRAL TO DRIVER OUTSIDE DOOR HANDLE) DRIVER'S DOOR ECM (1.6L TURBO) PCM (2.4L, 2.0L TURBO) EMS COM ENG RPM ENG SPD SIG GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GROUND GRY WIRE GRY/ORG WIRE I/P-D IMMO DATA LINE LED LOCK MODULE 2 FUSE MODULE 6 FUSE MODULE 9 FUSE NCA WIRE ON INPUT ON/START INPUT P POSITION P POSITION SWITCH PASS DR LCK/UNLCK SW PNK WIRE RED WIRE SMART JUNCTION BLOCK SMART KEY CONTROL MODULE (RIGHT END OF DASH) SSB ILL GND SSB ILL PWR START FEEDBACK SIG START RLY O/P STARTING/ CHARGING SYSTEM VEHICLE SPD WHT WIRE YEL WIRE YEL/BLK WIRE YEL/ORG WIRE

Go to component -> Immobilizer circuit, except hybrid w/ smart key system (1 of 3) -> BRN WIRE

brn wiring diagram (44 of 280)

2.0L HYBRID, 2.0L PLUG IN HYBRID 2.0L PLUG-IN HYBRID ACC RLY CTRL ANT #1 GND ANT #1 PWR ANT 2 GND ANT 2 PWR BCM BLK WIRE BLK/ORG WIRE BLU WIRE BLU/ORG WIRE BRAKE SWITCH FUSE BRN WIRE BUMPER ANT GND BUMPER ANT PWR C-CAN C-CAN HIGH C-CAN LOW CENTER REAR OF LUGGAGE COMPT) CLUSTER FUSE COMPUTER DATA LINES SYSTEM DRV DR ANT GND DRV DR ANT PWR EXTERNAL ANTENNA EXTERNAL BUZZER GND 2 GND SIG 2 GRN WIRE GRN/ORG WIRE HOT AT ALL TIMES I/P-D I/P-E IGPM IMMO GND IMMO IND IMMO PWR INSTRUMENT CLUSTER INTERNAL RECEIVER KEY ILL MEMORY POWER CPU MEMORY POWER LOAD MICOM NCA WIRE ORG/ WIRE ORG/BLK WIRE PASS DR ANT GND PASS DR ANT PWR POWER DISTRIBUTION SYSTEM RED WIRE RELAY ENERGIZED RIGHT END OF DASH) SMART KEY ANTENNA (INTERIOR 1) SMART KEY ANTENNA (INTERIOR 2) SMART KEY BUMPER ANTENNA SMART KEY CONTROL MODULE (RIGHT END OF DASH) SMART KEY FUSE SMART KEY TRUNK ANTENNA SSB ACC LED SSB IGN LED TRANSCEIVER/ TRUNK ANT GND TRUNK ANT PWR WHT WIRE WIRELESS CHARGER SIG YEL WIRE YEL/ORG WIRE

Go to component -> Immobilizer circuit, hybrid (3 of 3) -> BRN WIRE

brn wiring diagram (45 of 280)

B+3 FUSE BLK WIRE BRN WIRE C-CAN CLUSTER FUSE COMPUTER DATA LINES SYSTEM CONSTANT CRASH PAD SWITCH CURRENT DETENT OUT DIAL ILL DOWN DOWN IN E/R JUNCTION BLOCK GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START HOT W/ LEAK CURRENT AUTO CUT DEVICE RELAY ENERGIZED I/P-D ILL ILL (-) OUT INSTRUMENT CLUSTER INTERIOR LAMP FUSE LEAK CURRENT AUTO CUT DEVICE M-CAN MEMORY 1 FUSE MICOM MULTI FUSE (TYPE A) ORG/ WIRE POINTER ILL RED WIRE REG RHEOSTAT S GND SMART JUNCTION BLOCK TAIL LAMP IN TRANSCEIVER/ UP IN WHT WIRE YEL WIRE

Go to component -> Instrument illumination circuit, except hybrid (1 of 3) -> BRN WIRE

brn wiring diagram (46 of 280)

4.0 A/C CONTROL MODULE A/V, NAVIGATION HEAD UNIT AUDIO AUTOMATIC A/C AUX, USB JACK B-CAN BLK WIRE BLK/ORG WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BRN WIRE CIGARETTE LIGHTER ILLUMINATION CLOCK- SPRING COMPUTER DATA LINES SYSTEM CONSOLE SWITCH DETENT DETENT OUT GROUND DISTRIBUTION SYSTEM GRY WIRE HAZARD SWITCH I/P-A I/P-B I/P-E ILL IPS 3 CTRL IPS CONTROL MODULE KEYBOARD LEFT AUDIO REMOTE CONTROL SWITCH LOW HIGH MANUAL A/C OUT OVERHEAD CONSOLE LAMP PIO PIO 4.0 PWR RED WIRE RIGHT END OF DASH) RIGHT TRIP REMOTE CONTROL SWITCH SHIFT LEVER INDICATOR SMART JUNCTION BLOCK SMART KEY CONTROL MODULE STEERING WHEEL) STOP/START BUTTON SWITCH W/ EPB W/O EPB W/ NAVIGATION W/ SMART KEY W/ SUNROOF W/O NAVIGATION WHT WIRE YEL WIRE

Go to component -> Instrument illumination circuit, except hybrid (2 of 3) -> BRN WIRE

brn wiring diagram (47 of 280)

AUTO B-CAN HIGH B-CAN LOW BCM BLK WIRE BLK/ORG WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DETENT DRIVER DOOR MOOD LAMP DRIVER IMS SWITCH DRIVER'S DOOR FRONT AIR VENTILATION SEAT CONTROL MODULE FRONT SEAT WARMER CONTROL MODULE FUEL FILLER, TRUNK OPEN SWITCH GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRY WIRE HEADLAMP IGNITION KEY ILLUMINATION, DOOR WARNING SWITCH KEY HOLE ILL OUT LEFT "C" PILLAR) LEFT REAR POWER WINDOW SWITCH LIGHT SW SIG MULTI- FUNCTION SWITCH NCA WIRE ORG/BLK WIRE OUT OUT DETENT PASSENGER DOOR MOOD LAMP PASSENGER POWER WINDOW SWITCH PASSENGER'S DOOR POWER WINDOW MAIN SWITCH REAR SEAT WARMER CONTROL MODULE REAR USB CHARGER 1 REAR USB CHARGER 2 RED WIRE RED/YEL WIRE RIGHT END OF DASH) RIGHT REAR POWER WINDOW SWITCH TAIL W/ AIR VENTILATION SEAT W/ AUTO UP/DOWN, SAFETY W/ SMART KEY W/O AIR VENTILATION SEAT W/O AUTO UP/DOWN, SAFETY W/O SMART KEY WHT/BLU WIRE WHT/YEL WIRE WIPER, LIGHT GND YEL WIRE YEL/BLK WIRE

Go to component -> Instrument illumination circuit, except hybrid (3 of 3) -> BRN WIRE

brn wiring diagram (48 of 280)

B+3 FUSE BLK WIRE BRN WIRE C-CAN CLUSTER FUSE COMPUTER DATA LINES SYSTEM CONSTANT CRASH PAD SWITCH CURRENT DETENT OUT DIAL LCD ILL DOWN DOWN IN E/R JUNCTION BLOCK GND SIG 1 GND SIG 3 GRN WIRE HOT AT ALL TIMES I/P-D I/P-E IGPM ILL ILL (-) OUT INSTRUMENT CLUSTER M-CAN MICOM MODULE 3 FUSE MONITOR MULTI FUSE (TYPE A) ORG/ WIRE POINT LCD ILL RED WIRE RELAY ENERGIZED RHEOSTAT TAIL LAMP IN TRANSCEIVER/ UP IN WHT WIRE YEL WIRE

Go to component -> Instrument illumination circuit, hybrid (1 of 3) -> BRN WIRE

brn wiring diagram (49 of 280)

2.0L PLUG-IN HYBRID A/C CONTROL MODULE A/V, NAVIGATION HEAD UNIT ACC ILL OUT ATM SHIFT LEVER INDICATOR AUDIO AUX, USB JACK B-CAN BLK WIRE BLK/ORG WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BRN WIRE CIGARETTE LIGHTER ILLUMINATION CLOCK- SPRING COMPUTER DATA LINES SYSTEM CONSOLE SWITCH DETENT OUT FUEL FILLER, TRUNK OPEN SWITCH GRN WIRE GROUND DISTRIBUTION SYSTEM GRY WIRE HAZARD SWITCH HOT AT ALL TIMES I/P-A I/P-B I/P-D I/P-E IGN ILL OUT IGPM ILL IPS 3 CTRL IPS CONTROL MODULE KEYBOARD LEFT AUDIO REMOTE CONTROL SWITCH LOW HIGH MEM PWR OVERHEAD CONSOLE LAMP RED WIRE RIGHT END OF DASH) SMART KEY CONTROL MODULE SMART KEY FUSE SSB ILL GND SSB ILL PWR STEERING WHEEL) STOP/START BUTTON SWITCH W/ EPB W/O EPB W/ UVO W/O UVO W/ NAVIGATION W/O NAVIGATION W/ SMART KEY W/ SUNROOF WHT WIRE YEL WIRE

Go to component -> Instrument illumination circuit, hybrid (2 of 3) -> BRN WIRE

brn wiring diagram (50 of 280)

2.0L HYBRID 2.0L PLUG-IN HYBRID AUTO B-CAN HIGH B-CAN LOW BCM BLK WIRE BLK/ORG WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DETENT DRIVER DOOR MOOD LAMP DRIVER IMS SWITCH DRIVER'S DOOR FRONT AIR VENTILATION SEAT CONTROL MODULE FRONT SEAT WARMER CONTROL MODULE GND (BCM) GRN WIRE GRN/BLK WIRE GRN/RED WIRE GROUND DISTRIBUTION SYSTEM GRY WIRE HEADLAMP KEY HOLE ILL OUT LEFT REAR POWER WINDOW SWITCH LIGHT SW OUT LIGHT SW SIG MULTI- FUNCTION SWITCH ON/ST INPUT ORG/BLK WIRE OUT OUT DETENT PASSENGER DOOR MOOD LAMP PASSENGER POWER WINDOW SWITCH PASSENGER'S DOOR POWER WINDOW MAIN SWITCH REAR SEAT WARMER CONTROL MODULE REAR USB CHARGER RED WIRE RED/YEL WIRE RIGHT END OF DASH) RIGHT REAR POWER WINDOW SWITCH TAIL W/ AIR VENTILATION SEAT W/ MEMORY W/O AIR VENTILATION SEAT W/O MEMORY WHT/BLU WIRE WHT/YEL WIRE WIPER, LIGHT GND YEL WIRE

Go to component -> Instrument illumination circuit, hybrid (3 of 3) -> BRN WIRE
