Installation
- Install the windshield wiper switch.
- Connect the wiper switch connector.
- Install the steering column upper and lower shrouds.
Removal
| CAUTION | When servicing the washer pump, be careful not to damage the washer pump seal. Do not operate the washer pump before filling the washer reservoir. Failure to do so could result in premature pump failure. |
Scheme 19
Scheme 20
- Disconnect the negative (-) battery terminal.
- Remove the front bumper cover. (For Coupe, refer to «FRONT BUMPER»(ref-362257-S03855621912010060400000) . For Sedan, refer to «FRONT BUMPER»(ref-362262-S36918342852010060400000) ).
- Remove the washer hose and the washer motor connector (A).
- Remove the washer reservoir (A) after removing 2 bolts.
- Install the washer reservoir. NOTE: Before installing the pump motor, check the filter for foreign material or contamination. if necessary, clean the filter into the pump motor.
- Install the washer motor and connect the washer hose, the motor.
- Install the front bumper cover.
Scheme 21
Scheme 22
- With the washer motor connected to the reservoir tank, fill the reservoir tank with water. NOTE: Before filling the reservoir tank with water, check the filter for foreign material or contamination. if necessary, clean the filter.
- Connect positive (+) battery cables to terminal 1 and negative (-) battery cables to terminal 2 respectively.
- Check that the motor operates normally and the washer motor runs and water sprays from the front nozzles.
- If they are abnormal, replace the washer motor (A). (1. Windshield washer (+), 2. Ground)
Scheme 23
Scheme 24
- Wiper low and wiper high do not work.
- When washer switch is on, wiper does not work.
