Multifunction Switch: Specifications Kia Forte I

Steering Column Switches 16 illustrations ~220 words

Specifications

ItemsSpecifications
Rated voltageDC 12V
Operating temperature range30°C ~ +80°C (-22 ~ +176°F)
Rated loadDimmer & passing switchHigh : 0.2A (Relay load) Low : 0.2A (Relay load) Passing : 0.2A (Relay load)
Lighting switchLighting : 0.2A (Relay load)
Turn signal & lane change switch6.6 ± 0.5A (Lamp load)
Front & rear fog lamp switch0.2A (Relay load)
Wiper & mist switchLow, High : 4.5A (Motor load) Intermittent : 0.22 ± 0.5A (Relay load) Lock : Max. 28A (Motor load)
Washer switch4A (Motor load)
Variable intermittent volume switchMax. 25mA

GENERAL SPECIFICATIONS

Scheme 1

Scheme 1: Components (1)

Scheme 2

Scheme 2: Components (2)

Scheme 3

Scheme 3: Lighting Switch Inspection
  1. With the multi function switch in each position, make sure that continuity exists between the terminals . If continuity is not as specified in «LIGHTING SWITCH CONTINUITY SPECIFICATIONS»(ref-362267-S26733847932010060400000) , replace the multi-function switch

Lighting Switch Continuity Specifications

Lighting Switch

Scheme 4

Scheme 4: Lighting Switch Continuity Specifications

Dimmer And Passing Switch

Scheme 5

Scheme 5

Turn Signal Switch

Scheme 6

Scheme 6

Front Fog Lamp

Scheme 7

Scheme 7

Scheme 8

Scheme 8: Wiper And Washer Switch Inspection
  1. With the multi function switch in each position, make sure that continuity exists between the terminals . If continuity is not as specified in «WIPER AND WASHER SWITCH CONTINUITY SPECIFICATIONS»(ref-362267-S00822270952010060400000) , replace the multi-function switch.

Wiper And Washer Switch Continuity Specifications

Wiper Switch

Scheme 9

Scheme 9: Wiper And Washer Switch Continuity Specifications

Washer Switch

Scheme 10

Scheme 10: Removal

Scheme 11

Scheme 11

Scheme 12

Scheme 12

Scheme 13

Scheme 13

Scheme 14

Scheme 14

Scheme 15

Scheme 15

Scheme 16

Scheme 16
  1. Disconnect the negative (-) battery terminal.
  2. Remove the steering column upper (A) and lower (B) shrouds after removing 3 screws.
  3. Disconnect the light switch connector (A) and the wiper switch connector (B) .
  4. Remove the wiper switch (A) by pushing the lock pin (B) . NOTE: When removing the wiper & washer switch only, release the lock of wiper switch without removing the steering wheel.
  5. Remove the clock spring (A) .
  6. Loosen the screws from the multifunction switch assembly (A) .
  7. Remove the multifunction switch assembly (A) .
