Button Engine Start System: Removal & Installation Kia Forte I

Ignition Switch/steering Lock 15 illustrations ~302 words

Installation

  1. Install the start/stop button.
  2. Install the start/stop button cover.

Scheme 3

Scheme 3: Component

Scheme 4

Scheme 4: Removal

Scheme 5

Scheme 5
  1. Disconnect the negative (-) battery terminal.
  2. Remove the crash pad lower panel (A). (For Coupe, refer to «CRASH PAD»(ref-362224-S30236245892010060400000) . For Sedan, refer to «CRASH PAD»(ref-362245-S13817783762010060400000) .)
  3. Remove the fob holder (A) after removing the screws and connector.
  1. Install the fob holder assembly.
  2. Install the crash pad lower panel.

Scheme 6

Scheme 6: Component

Scheme 7

Scheme 7: Removal

Scheme 8

Scheme 8

Scheme 9

Scheme 9
  1. Disconnect the negative (-) battery terminal.
  2. Remove the steering column upper and lower shrouds (A).
  3. Disconnect the electronic steering column lock connector (A).
  4. Remove the electronic steering column lock (A) after removing the shear bolts. (Refer to «STEERING COLUMN AND SHAFT»(ref-362239-S17782797232010060400000) )
  1. Install the electronic steering column lock. (Refer to «STEERING COLUMN AND SHAFT»(ref-362239-S17782797232010060400000) ) Tightening torque: 7 ~ 13 N.m (0.7 ~ 1.3 kgf.m, 5 ~ 9.4 lb.ft)
  2. Install the steering column.

Scheme 10

Scheme 10: Component

Scheme 11

Scheme 11: System Circuit Diagram

Scheme 12

Scheme 12: Removal

Scheme 13

Scheme 13
  1. Disconnect the negative (-) battery terminal.
  2. Remove the steering column assembly. (Refer to «STEERING COLUMN AND SHAFT»(ref-362239-S17782797232010060400000) )
  3. Remove the PDM relay, before removing the PDM.
  4. Disconnect the power distribution module (PDM) connectors.
  5. Remove the power distribution module (A) after loosening nuts and bolts.
  1. Install the power distribution module and PDM relay.
  2. Install the steering column assembly.

Scheme 14

Scheme 14: PDM Diagnosis With GDS

Scheme 15

Scheme 15

Scheme 16

Scheme 16

Scheme 17

Scheme 17
  1. It will be able to diagnose defects of Smart key with GDS quickly. GDS can operates actuator forcefully, input/output value monitoring and self diagnosis.
  2. Select model and "Smart key system (Button start)" menu if you want to check PDM.
  3. Select "PDM" in the menu.
  4. Select "Current Data", if you want to check current data of PDM. It provides the input/output status of each module.
  5. If you want to check PDM data operation forcefully, select "Actuation test".
