Lighting System: Specifications Kia Forte I

Exterior Lights 4 illustrations ~220 words

Specification

ItemsBulb Wattage (W)
FrontHead lamp (High/Low)55/55
Turn signal lamp28
Fog lamp35
Turn signal lamp (Power Door Mirrors)5
Position8
Side marker8
RearO/STurn signal lamp27
Side marker8
Stop/tail lamp (Stop/Tail)28/8
I/STail lamp8
Fog lamp
Back up lamp16
High mounted stop lamp (HMSL)16
License plate lamp5
RoomOver head lamp10
Room lamp10
TrunkLuggage lamp5

BULB WATTAGE SPECIFICATIONS

Scheme 1

Scheme 1: Component Location

Scheme 2

Scheme 2: Head Lamp Relay/Front Lamp Relay

Scheme 3

Scheme 3
  1. Disconnect the negative (-) battery terminal.
  2. Pull out the relay from the engine compartment relay box. Head lamp (Low) relay Head lamp (High) relay Front fog lamp relay
  3. Check for continuity between terminals. There should be continuity between the No. 87 and No. 30 terminals when power and ground are connected to the No. 86 and No. 85 terminals.
  4. There should be no continuity between the No. 87 and No. 30 terminals when power is disconnected.

Scheme 4

Scheme 4: Tail Lamp
  1. Disconnect the negative (-) battery terminal.
  2. Remove the crash pad lower panel. (For Coupe, refer to «CRASH PAD»(ref-362224-S30236245892010060400000) . For Sedan, refer to «CRASH PAD»(ref-362245-S13817783762010060400000) .)
  3. Remove the junction box.
  4. Check for continuity between the terminals. There should be continuity between the No. 2 terminal in the I/P-H and the No. 15 (LH) or 4 (RH) terminal in the I/P-G when power and ground are connected to the No. 2 terminal in the I/P-H and the No. 6 terminal in the I/P-D. There should be no continuity between the No. 2 terminal in the I/P-H and the No. 15 (LH) or 4 (RH) terminal in the I/P-G when power and ground are connected to the No. 2 terminal in the I/P-H and the No. 6 terminal in the I/P-D.
