Instrument cluster — Clock circuit Kia Cerato IV
All systems — 40 systems
- Air conditioning 1.6l turbo 2
- Air conditioning 2.0l 2
- Anti-lock brakes
- Anti-theft 3
- Body control modules 2
- Computer data lines
- Cooling fan 1.6l turbo
- Cooling fan 2.0l
- Cruise control 1.6l turbo
- Cruise control 2.0l
- Defoggers 2
- Electronic power steering
- Engine performance 1.6l turbo 2
- Engine performance 2.0l
- Exterior lights 1.6l turbo
- Exterior lights 2.0l
- Ground distribution
- Headlights 2
- Horn
- Instrument cluster 3
- Interior lights 2
- Navigation 5
- Power distribution 1.6l turbo
- Power distribution 2.0l
- Power door locks
- Power mirrors 2
- Power seats 5
- Power top/sunroof
- Power windows 2
- Radio 4
- Shift interlock 1.6l turbo
- Shift interlock 2.0l
- Starting/charging 1.6l turbo 2
- Starting/charging 2.0l 2
- Supplemental restraints
- Transmission 1.6l turbo
- Transmission 2.0l
- Trunk, tailgate, fuel door
- Warning systems 2
- Wiper/washer
Components on these wiring diagrams 7
Click a component to highlight it on every diagram it appears on.
