Rear Wiper/washer System: Overview Kia Carnival III

Scheme 22

Scheme 23

Scheme 24

1. Remove the tail gate trim. Refer to TAILGATE .
2. Detach the wiper cap (A), and then remove the rear wiper arm after removing the mounting nut (B). Tightening torque Nut (B): 10 ~ 13 N.m (1.0 ~ 1.3 kgf.m, 7.2 ~ 9.4 lb.ft)
3. Detach the wiper motor cover, and then remove the rear wiper cap & pad (B) after removing the mounting nut (A). NOTE: During installation, of the rear wiper cap and pad, ensure the arrow on the cap assembly is pointed upwards.
4. Disconnect the rear wiper motor connector (A) then remove the rear wiper motor (B) after removing 2 bolts. Tightening torque Bolts: 7 ~ 11 N.m (0.7 ~ 1.1 kgf.m, 5.1 ~ 8.0 lb.ft)
5. Installation is the reverse of removal.
