Power Windows: Other Kia Carnival III

Function Of Safety Power Window

When driver door power window auto-up switch is operated, safety function is activated.

Scheme 2

Scheme 3

Scheme 4

1. Safety function condition When the system detects a force of 100N during the window rising, window is reversed.
2. Length of window reversing (except when holding the auto-up switch) When jamming is detected within 4 mm ~ 300 mm from top of the door. --> Window is reversed until 350 mm from top of the door. When detect the jamming over the 300 mm from top of the door. --> Window is reversed until 50 mm from jamming position.
3. Length of window reversing (holding the auto-up switch) When detect the jamming during holding the auto-up switch. --> Window is reversed until 20 mm from jamming position.
4. Safety function is not available area

Safety function is not available within 4 mm from top of the door.

Initializing Method Of The Safety Power Window

1. Initializing of Battery Connection Power window operation before initializing Manual-Up/Down function is available Auto-Up function is not available (When holding the auto-up/down switch, window is operated as a Manual-Up/Down.) Initializing method Close the window in window open position, and holding the switch in window full close position more than 1 second.

Scheme 5

1. Remove (-) negative battery terminal.
2. Remove the front door trim panel. Refer to FRONT DOOR .
3. Remove the window motor (B) after disconnecting the motor connector (A) and mounting nuts.
4. Installation is the reverse of removal.

Scheme 6

1. Remove (-) negative battery terminal.
2. Remove the sliding door trim panel. Refer to REAR DOOR
3. Remove the door trim seal and glass.
4. Remove the door regulator.
5. Remove the power window motor (A) after disconnecting the motor connector and power window motor mounting nuts.
6. Installation is the reverse of removal.

Scheme 7

Scheme 8

1. Remove (-) negative battery terminal.
2. Remove the D pillar trim panel (A). Refer to INTERIOR TRIM .
3. Remove the quarter glass motor (B) after disconnecting the motor connector (A) and quarter glass motor mounting bolts and screws.
4. Installation is the reverse of removal.

Scheme 9

1. Remove (-) negative battery terminal.
2. Remove the rear door trim panel. Refer to REAR DOOR TRIM REPLACEMENT .
3. Disconnect the motor connector from the motor.
4. Connect the motor terminals directly to battery voltage (12V) and check that the motor operates smoothly. Next, reverse the polarity and check that the motor operates smoothly in the reverse direction. If the operation is abnormal, replace the motor.

Scheme 10

1. Remove (-) negative battery terminal.
2. Remove the sliding door trim panel. Refer to REAR DOOR .
3. Disconnect the motor connector from the motor.
4. Connect the motor terminals directly to battery voltage and check that the motor operates smoothly. Next, reverse the polarity and check that the motor operates smoothly in the reverse direction. If the operation is abnormal, replace the motor.

Scheme 11

1. Remove (-) negative battery terminal.
2. Remove the D pillar trim panel (A). Refer to INTERIOR TRIM .
3. Disconnect the motor connector from the motor.
4. Connect the motor terminals directly to battery voltage and check that the motor operates smoothly. Next, reverse the polarity and check that the motor operates smoothly in the reverse direction. If the operation is abnormal, replace the motor.

Scheme 12

Scheme 13

1. Remove (-) negative battery terminal.
2. Remove the front door trim panel. Refer to FRONT DOOR .
3. Disconnect the door module mounting screws (5 EA) after disconnecting the module connectors (3 EA) from the motor.
4. Remove the door module (DDM/ADM) (A) from the front door trim panel.
5. Installation is the reverse of removal.

Scheme 14

1. Remove (-) negative battery terminal.
2. Disconnect the connector (B) after removing the sliding power window switch (A) from the B pillar trim (C).
3. Installation is the reverse of removal.

Scheme 15

1. Remove (-) negative battery terminal.
2. Disconnect the connector (B) after removing the quarter glass switch (A) from the rear cargo area luggage trim.
3. Installation is the reverse of removal.
