Power Seat Electrical: Overview Kia Carnival III

Scheme 4

Scheme 5

1. Disconnect the negative (-) battery terminal.
2. Remove the seat cushion. Refer to SEAT CUSHION COVER REPLACEMENT .
3. Remove the front height motor (A) after loosening the mounting nuts (2 EA), bolt (1 EA) and removing connector.
4. Installation is the reverse of removal.

Scheme 6

1. Disconnect the negative (-) battery terminal.
2. Remove the seat cushion. Refer to SEAT CUSHION COVER REPLACEMENT .
3. Remove the rear height motor (A) after removing the mounting bolt (2 EA) and connector.
4. Installation is the reverse of removal.

Scheme 7

1. Disconnect the negative (-) battery terminal.
2. Remove the seat cushion. Refer to SEAT CUSHION COVER REPLACEMENT .
3. Remove the slide motor (A) after removing the mounting bolt (2 EA) and connector.
4. Installation is the reverse of removal.

Scheme 8

1. Disconnect the negative (-) battery terminal.
2. Remove the seat cushion. Refer to SEAT CUSHION COVER REPLACEMENT .
3. Remove the slide motor (A) after removing the mounting bolts (2 EA) and connector.
4. Installation is the reverse of removal.

Scheme 9

Scheme 10

1. Disconnect the negative (-) battery terminal.
2. Remove the seat back. Refer to SEAT BACK COVER REPLACEMENT .
3. Remove the seat shaft fixing clip (A) and seat shaft (B).
4. Remove the relining motor (A) after removing the mounting nut (1 EA) and connector.
5. Installation is the reverse of removal.
