Special Tools
SPECIAL TOOLS DESCRIPTION CHART Tool (Number and Name) Illustration Use 09222-32100 Valve stem oil seal installer Installation of the oil pump oil seal 09555-21000 Bar Removal and installation of the oil seal (Use with 09573-33100, 09573-33000, 09573-21000) 09561-11001 Steering wheel puller Removal of steering wheel 09568-4A000 Tie rod end puller Separation of the tie rod end bail joint 09572-21000 Oil pressure gauge Measurement of the oil pressure (Use with 09572-22100, 09572-21200) 09572-21200 Oil pressure gauge adapter Measurement of the oil pressure (Use with 09572-21000, 09572-22100) 09572-22100 Oil pressure gauge adapter Measurement of the oil pressure (Use with 09572-21000, 09572-21200) 09573-21100 Oil seal installer Installation of the back up washer and oil seal (Use with 09753-21000, 09573-33100, 09555-21000) 09573-33100 Oil seal guide Removal and installation of the oil seal (Use with 09573-21000, 09573-33000, 09555-21000) 09432-21600 Bearing installer Installing the pinion gear bearing 09434-14200 Counter shaft bearing installer Installing the gear box oil seal 09565-11100 Preload socket Measuring the pinion shaft preload 09573-21000 Oil seal installer guide Installation of oil seal
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
Scheme 12
Scheme 13
Scheme 14
Scheme 15
Scheme 16
- Start the engine and with the steering wheel in the straight ahead position.
- Measure the play while turning the steering wheel to the left and right. Standard value: Steering wheel free play : 30 mm (1.1 in)
- If the play exceeds the standard value, inspect the connection between the steering shaft and tie rod ends.
