Ignition Switch Assembly Kia Carnival III

Ignition Switch/steering Lock 5 illustrations ~104 words

Scheme 1

Scheme 1: Replacement
Scheme 1: Replacement

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5
  1. Disconnect the negative (-) battery terminal.
  2. Remove the crash pad lower panel. Refer to CRASH PAD .
  3. Remove the screws (2 EA) and trip switch connector. Then remove the crash fascia panel (B).
  4. Remove the ignition switch (A) after loosening the screw with IG ON and disconnecting the 6P connector.
  5. Remove the door warning switch and key illumination lamp (A) after loosening the screws (B) and disconnecting the 6P connector.
  6. Remove the key lock cylinder (C) after pushing lock pin (B) with key ACC.
  7. Installation is the reverse of removal procedure.
