Heater System: Removal & Installation Kia Carnival III

Replacement

1. Disconnect the negative (-) battery terminal.
2. Remove the driver's crash pad lower panel. Refer to LOWER PANEL REPLACEMENT .
3. Disconnect the temperature control actuator connector (A) after removing the air duct.
4. Loosen the mounting screw and then remove the temperature control actuator (B).

Scheme 17

Scheme 18

1. Installation is the reverse order of removal.

1. Disconnect the negative (-) battery terminal.
2. Remove the driver's crash pad lower panel. Refer to LOWER PANEL REPLACEMENT .
3. Disconnect the mode control actuator connector (A) after removing the air duct.
4. Loosen the mounting screws and then remove the mode control actuator (B).

Scheme 19

Scheme 20

1. 5. Installation is the reverse order of removal.
