Fuses & Relays: Overview Kia Carnival III

Fuses & Circuit Breakers 18 illustrations ~374 words

Scheme 1

Scheme 1: Component Location
Scheme 1: Component Location

Scheme 2

Scheme 2: Front Area Module (FAM)
Scheme 2: Front Area Module (FAM)

CIRCUIT

FUSE(A)Circuit Protected
FRT/RR WASHER10AFRONT WASHER MOTOR RELAY, REAR WASHER MOTOR RELAY
STOP LAMP20ASTOP LAMP SWITCH
KEY SW #125AIGNITION SWITCH
STOP SIGNAL7.5AABS CONTROL MODULE, ESC MODULE, PCM
A/C COMP7.5AA/C COMP RELAY
ATM15AATM RELAY
FRT DEICER15AWINDSHIELD DEFOGGER RELAY
HORN15AHORN RELAY
ECU #110AA/C COMP RELAY, PCM, MASS AIR FLOW SENSOR, IMMOBILIZER MODULE
O2 DN10AOXYGEN SENSOR #3, OXYGEN SENSOR #4
ECU #215APCM, VARIABLE INTAKE MANIFOLD VALVE, COOLING FAN RELAY, PCSV, OCV, CCV
O2 UP10AOXYGEN SENSOR #1, OXYGEN SENSOR #2
IGN COIL20AIGNITION COIL #1 ~ #6, CONDENSER #1, #2
INJECTOR15AINJECTOR #1 - #6, PCM
P/TRAIN7.5AMAIN RELAY, BURGLAR ALARM RELAY, PCM
FUEL PUMP15AFUEL PUMP RELAY
ABS #140AABS CONTROL MODULE, ESC MODULE
ABS #220AABS CONTROL MODULE, ESC MODULE
FRT WIPER30AFRONT WIPER ON RELAY
KEY SW #230ASTART RELAY, IGNITION SWITCH
FRT BLOWER40AFRONT BLOWER RELAY
RR BLOWER30AREAR BLOWER RELAY
IPM #150AIPM
IPM #250AIPM
IPM #350AIPM
RAM #150ARAM
RAM #250ARAM
RAM #350ARAM
* USE THE DESIGNATED FUSE ONLY

FUSE SPECIFICATION

  1. Be sure there is no play in the fuse holders, and that the fuses are held securely.
  2. Are the fuse capacities for each circuit correct?
  3. Are there any blown fuses?

If a fuse is to be replaced, be sure to use a new fuse of the same capacity. Always determine why the fuse blew first and completely eliminate the problem before installing a new fuse.

Scheme 3

Scheme 3: Relay
Scheme 3: Relay

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8
  1. Be sure that the relays are held the each module securely.
  2. Are the relay types for each circuit correct?
  3. If system of some relay is not operate accurately, replace with a new one and check the system.

Scheme 9

Scheme 9: Front Area Module (FAM)
Scheme 9: Front Area Module (FAM)

Scheme 10

Scheme 10
Scheme 10
  1. Disconnect the negative (-) battery terminal.
  2. Remove the FAM cover of engine room.
  3. Remove the FAM connectors (2 EA) (A) and battery terminal nut (1 EA) (B).
  4. Remove FAM mounting bolts (3 EA) (A) and remove the FAM (B) from splash shield (C).
  5. Disconnect the connector from splash shield.
  6. Installation is the reverse of removal.

Scheme 11

Scheme 11: Instrument Panel Module (IPM)
Scheme 11: Instrument Panel Module (IPM)

CIRCUIT

FUSE(A)Circuit Protected
ACC7.5APOWER OUTSIDE MIRROR SWITCH, AUDIO, DIGITAL CLOCK & TELLTALE, RSE MODULE, KEY INTERLOCK RELAY
P/OUTLET #215ACIGARETTE LIGHTER
START7.5ABURGLAR ALARM RELAY, TRANSAXLE RANGE SWITCH
AIRBAG IND7.5AINSTRUMENT CLUSTER
ENG7.5AATM LEVER SWITCH, STOP LAMP SWITCH, INPUT SPEED SENSOR, OUTPUT SPEED SENSOR, TRANSAXLE RANGE SWITCH, PCM, VEHICLE SPEED SENSOR
IG17.5ATRIP COMPUTER, BACK WARNING BUZZER, RHEOSTAT, TIRE PRESSURE MONITORING MODULE, ESC SWITCH, INSTRUMENT CLUSTER, OC SENSOR, MULTIFUNCTION SWITCH
ABS7.5AABS CONTROL MODULE, ESC MODULE, YAW RATE SENSOR, STEERING ANGLE SENSOR, MULTIPURPOSE CHECK CONNECTOR
AIRBAG15ADIGITAL CLOCK & TELLTALE, SRS CONTROL MODULE
TPMS7.5ATIRE PRESSURE MONITORING MODULE, FRONT INITIATOR LH, RH, REAR INITIATOR LH, RH
PEDAL15AADJUST PEDAL RELAY
P/OUTLET #115AFRONT POWER OUTLET
ASS P/SEAT20AASSISTOR POWER SEAT MODULE
DRV P/SEAT30ALIMIT SWITCH, DRIVER POWER SEAT MODULE
OBD-II7.5ADATA LINK CONNECTOR, MULTIPURPOSE CHECK CONNECTOR
ROOM7.5AOC SENSOR, HOME LINK, VANITY LAMP LH, RH, MAP LAMP, A/C CONTROL MODULE, REAR ROOM LAMP SWITCH
K/LOCK7.5AKEY INTERLOCK RELAY
ILLUMI7.5AIPM
AMP25AAMP
SEAT WARMER20ASEAT WARMER RELAY
SUNROOF25ASUNROOF MODULE
AUDIO15ASTEP LAMP LH, RH, AUDIO, RSE MODULE
MEMORY7.5AA/C CONTROL MODULE, DIGITAL CLOCK & TELLTALE, INSTRUMENT CLUSTER, TRIP COMPUTER, DOOR MODULE, FAM, DRIVER POWER SEAT MODULE
IG2 #17.5AMULTIFUNCTION SWITCH, A/C CONTROL MODULE, HOME LINK, ELECTRO CHROMIC MIRROR, RAIN SENSOR, RELAY BOX
IG2 #27.5ADOOR MODULE, REAR A/C CONTROL SWITCH, FAM, DRIVER POWER SEAT MODULE
DDM30ADRIVER DOOR MODULE
ADM30AASSISTOR DOOR MODULE
* USE THE DESIGNATED FUSE ONLY

FUSE SPECIFICATION

Scheme 12

Scheme 12: Rear Area Module (RAM)
Scheme 12: Rear Area Module (RAM)

CIRCUIT

FUSE(A)Circuit Protected
PSD-LH30APOWER SLIDING DOOR MODULE LH
PSD-RH30APOWER SLIDING DOOR MODULE RH
RR-DEFOG25ARR DEFOG RELAY, REAR DEFOGGER
POWER TAIL GATE30APOWER TAIL GATE MODULE
P/QUARTER10AQUARTER GLASS OPEN RELAY LH, QUARTER GLASS CLOSE RELAY LH QUARTER GLASS OPEN RELAY RH, QUARTER GLASS CLOSE RELAY RH
RR WIPER15ARR WIPER RELAY, REAR WIPER MOTOR
RR D/LOCK20AS/DOOR LOCK RELAY, S/DOOR UNLOCK RELAY SLIDING DOOR LOCK ACTUATOR, TAIL GATE LOCK ACTUATOR
PR P/OTLT-LH15AREAR POWER OUTLET LH
RR P/OTLT-RH15AREAR POWER OUTLET RH
FUEL DOOR15AFUEL FILLER RELAY, FUEL FILLER ACTUATOR
RR P/WIN-LH25AS/DOOR WINDOW RELAY (UP) LH, S/DOOR WINDOW RELAY (DN) LH
RR P/WIN-RH25AS/DOOR WINDOW RELAY (UP) RH, S/DOOR WINDOW RELAY (DN) RH
LUGGAGE7.5ALUGGAGE LAMP, POWER TAIL GATE ON/OFF SWITCH
* USE THE DESIGNATED FUSE ONLY

FUSE SPECIFICATION

  1. Be sure there is no play in the fuse holders, and that the fuses are held securely.
  2. Are the fuse capacities for each circuit correct?
  3. Are there any blown fuses?

If a fuse is to be replaced, be sure to use a new fuse of the same capacity. Always determine why the fuse blew first and completely eliminate the problem before installing a new fuse.

Scheme 13

Scheme 13: Relay
Scheme 13: Relay
  1. Be sure that the relays are held the each module securely.
  2. Are the relay types for each circuit correct?
  3. If system of some relay is not operate accurately, replace with a new one and check the system.

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15: Instrument Panel Module (IPM)
Scheme 15: Instrument Panel Module (IPM)

Scheme 16

Scheme 16
Scheme 16
  1. Disconnect the negative (-) battery terminal.
  2. Remove the crash pad lower panel (A). Refer to LOWER PANEL REPLACEMENT .
  3. Disconnect the receiver antenna cable and connectors (5 EA). Remove IPM mounting nuts (3 EA) and IPM (A).
  4. Installation is the reverse of removal procedures.

Description

The Integrated Circuit Module (ICM) relay (A) is united with many kinds of relays and installed side of the in-panel module.

Scheme 17

Scheme 17: Description
Scheme 17: Description

Scheme 18

Scheme 18
Scheme 18
