Fuel System - General Information: Other Kia Carnival III

Fuel System 4 illustrations ~324 words

Fuel Delivery System

ItemsSpecification
Fuel TankCapacity75 lit. (19.8 U.S. gal., 79.2 U.S. qt., 65.9 Imp. qt.)
Fuel FilterTypeHigh pressure type
Fuel Pressure RegulatorRegulated Fuel Pressure379.5 kPa (3.87 kgf/cm 2 , 55.0 psi)
Fuel PumpTypeElectrical, in-tank type
Driven byElectric motor

FUEL DELIVERY SYSTEM SPECIFICATION

Sensors

Barometric Pressure Sensor (BPS)

  1. Type: Piezo-resistive pressure sensor
  2. Specification
Pressure (kPa)Output Voltage (V)
10.00.50
55.02.21
100.03.93
115.04.50

VOLTAGE SPECIFICATION

Intake Air Temperature Sensor (IATS)

  1. Type: Thermistor type
  2. Specification
TemperatureResistance (kohms)
°C°F
404040.93 ~ 48.35
20413.89 ~ 16.03
0325.38 ~ 6.09
10503.48 ~ 3.90
20682.31 ~ 2.57
401041.08 ~ 1.21
601400.54 ~ 0.66
801760.29 ~ 0.34

RESISTANCE SPECIFICATION

Manifold Absolute Pressure Sensor (MAPS)

  1. Type: Piezo-resistive pressure sensor
  2. Specification
Pressure (kPa)Output Voltage (V)
20.00.79
46.661.84
101.324.0

VOLTAGE SPECIFICATION

Engine Coolant Temperature Sensor (ECTS)

  1. Type: Thermistor type
  2. Specification
TemperatureResistance (kohms)
°C°F
404048.14
20414.13 ~ 16.83
0325.79
20682.31 ~ 2.59
401041.15
601400.59
801760.32

RESISTANCE SPECIFICATION

Throttle Position Sensor (TPS) (integrated into ETC Module)

  1. Type: Variable resistor type
  2. Specification
Throttle Angle (°)Output Voltage (V)
TPS1TPS2
00.05.0
100.54.5
200.94.1
301.43.6
401.83.2
502.32.7
602.72.3
703.21.8
803.61.4
904.10.9
1004.50.5
1105.00.0

VOLTAGE SPECIFICATION

ItemSensor Resistance (kohms)
TPS13.6 ~ 6.0 (20°C (68°F))
TPS22.7 ~ 4.1 (20°C (68°F))

RESISTANCE SPECIFICATION

Crankshaft Position Sensor (CKPS)

  1. Type: Magnetic field sensitive sensor
  2. Specification
ItemSpecification
Coil Resistance (ohms)774 ~ 946 (20°C (68°F))
Air Gap (mm)0.5 ~ 1.5

COIL RESISTANCE SPECIFICATION

Camshaft Position Sensor (CMPS)

  1. Type: Hall effect type
  2. Specification
ItemSpecification
Output Voltage (V)High: 5.0V
Low: 0.7V
Air Gap (mm)0.5 ~ 1.5

VOLTAGE SPECIFICATION

Knock Sensor (KS)

  1. Type: Piezo-electricity type
  2. Specification
ItemSpecification
Capacitance (pF)950 ~ 1, 350

CAPACITANCE SPECIFICATION

Heated Oxygen Sensor (HO2S)

  1. Type: Zirconia (ZrO2) Type
  2. Specification
A/F Ratio (lambda)Output Voltage (V)
RICHMin. 0.8
LEANMax. 0.1

VOLTAGE SPECIFICATION

ItemSpecification
Heater Resistance (ohms)3.3 ~ 4.1 (20°C (68°F))

HEATER RESISTANCE SPECIFICATION

CVVT Oil Temperature Sensor (OTS)

  1. Type: Thermistor type
  2. Specification
TemperatureResistance (kohms)
°C°F
404052.15
20416.52
0326.0
20682.45
401041.11
601400.54
801760.29

RESISTANCE SPECIFICATION

Accelerator Position Sensor (APS)

  1. Type: Variable resistor type
  2. Specification
Accelerator PositionOutput Voltage (V)
APS1APS2
C.T.0.7 ~ 0.80.27 ~ 0.47
W.O.T.3.8 ~ 4.41.75 ~ 2.35

VOLTAGE SPECIFICATION

Fuel Tank Pressure Sensor (FTPS)

  1. Type: Piezo - Resistivity type
  2. Specification
Pressure (kPa)Output Voltage (V)
3.750.5
02.5
+3.754.5

VOLTAGE SPECIFICATION

Actuators

Injector

  1. Specification
ItemSpecification
Coil Resistance (ohms)13.8 ~ 15.2 (20°C (68°F))

COIL RESISTANCE SPECIFICATION

ETC Motor (integrated into ETC Module)

  1. Specification
ItemSpecification
Coil Resistance (ohms)1.275 ~ 1.725 (20°C (68°F))

COIL RESISTANCE SPECIFICATION

Purge Control Solenoid Valve (PCSV)

  1. Specification
ItemSpecification
Coil Resistance (ohms)22.0 ~ 26.0 (20°C (68°F))

COIL RESISTANCE SPECIFICATION

CVVT Oil Control Valve (OCV)

  1. Specification
ItemSpecification
Coil Resistance (ohms)9.4 ~10.4 (20°C (68°F))

COIL RESISTANCE SPECIFICATION

Variable Intake Solenoid (VIS) Valve

  1. Specification
ItemSpecification
Coil Resistance (ohms)30.0 ~ 35.0 (20°C (68°F))

COIL RESISTANCE SPECIFICATION

Ignition Coil

  1. Type: Stick type
  2. Specification
ItemSpecification
Primary Coil Resistance (ohms)0.62 ± 10% (20°C (68°F))
Secondary Coil Resistance (k)7.0 ± 15% (20°C (68°F))

COIL RESISTANCE SPECIFICATION

Canister Close Valve (CCV)

  1. Specification
ItemSpecification
Coil Resistance (ohms)19.8 ~ 21.8 (20°C (68°F))

COIL RESISTANCE SPECIFICATION

Service Standard

ItemSpecification
Ignition Timing (°)BTDC 8 ± 10
Idle Speed (RPM)A/C OFFNeutral, N, P-range580 ± 100
D-range550 ± 100
A/C ONNeutral, N, P-range580 ± 100
D-range550 ± 100

IGNITION TIMING SPECIFICATION

Engine Control System

ItemKgf.mN.m
ECM bracket installation bolt0.8 ~ 1.27.8 ~ 11.8
ECM bracket installation nut0.4 ~ 0.63.9 ~ 5.9
Barometric pressure sensor installation bolt0.4 ~ 0.63.9 ~ 5.9
Manifold absolute pressure sensor installation bolt0.8 ~ 1.27.8 ~ 11.8
Crankshaft position sensor installation bolt0.7 ~ 1.06.9 ~ 9.8
Camshaft position sensor (Bank 1/Intake) installation bolt0.7 ~ 1.06.9 ~ 9.8
Camshaft position sensor (Bank 1/Exhaust) installation bolt0.7 ~ 1.06.9 ~ 9.8
Camshaft position sensor (Bank 2/Intake) installation bolt0.7 ~ 1.06.9 ~ 9.8
Camshaft position sensor (Bank 2/Exhaust) installation bolt0.7 ~ 1.06.9 ~ 9.8
Knock sensor (Bank 1) installation bolt1.6 ~ 2.415.7 ~ 23.5
Knock sensor (Bank 2) installation bolt1.6 ~ 2.415.7 ~ 23.5
Heated oxygen sensor (Bank 1/Sensor 1) installation3.6 ~ 4.635.3 ~ 45.1
Heated oxygen sensor (Bank 1/Sensor 2) installation3.6 ~ 4.635.3 ~ 45.1
Heated oxygen sensor (Bank 2/Sensor 1) installation3.6 ~ 4.635.3 ~ 45.1
Heated oxygen sensor (Bank 2/Sensor 2) installation3.6 ~ 4.635.3 ~ 45.1
CVVT oil temperature sensor installation3.5 ~ 4.534.3 ~ 44.1
VCM position sensor installation screw0.4 ~ 0.64.0 ~ 6.0
ETC module installation bolt0.8 ~ 1.27.8 ~ 11.8
ETC module stay installation bolt1.6 ~ 2.615.7 ~ 25.5
Purge control solenoid valve bracket installation bolt0.8 ~ 1.27.8 ~ 11.8
CVVT oil control valve (Bank 1/Intake) installation bolt1.0 ~ 1.29.8 ~ 11.8
CVVT oil control valve (Bank 1/Exhaust) installation bolt1.0 ~ 1.29.8 ~ 11.8
CVVT oil control valve (Bank 2/Intake) installation bolt1.0 ~ 1.29.8 ~ 11.8
CVVT oil control valve (Bank 2/Exhaust) installation bolt1.0 ~ 1.29.8 ~ 11.8
Variable intake solenoid valve 1 installation nut0.6 ~ 0.95.4 ~ 8.3
Variable intake solenoid valve 2 installation nut0.6 ~ 0.95.4 ~ 8.3
Variable charge motion actuator installation bolt0.8 ~ 1.18.0 ~ 11.0
Ignition coil installation bolt1.0 ~ 1.29.8 ~ 11.8

TIGHTENING TORQUE SPECIFICATION

ItemKgf.mN.m
Fuel tank installation nut4.0 ~ 5.539.2 ~ 54.0
Fuel pump plate cover installation bolt8.0 ~ 10.078.5 ~ 98.1
Filler-neck assembly bracket installation nut0.4 ~ 0.63.9 ~ 5.9
Accelerator pedal module installation nut0.8 ~ 1.27.8 ~ 11.8
Delivery pipe installation bolt0.9 ~ 1.28.8 ~ 11.8

TIGHTENING TORQUE SPECIFICATION

Special Service Tools

SPECIAL SERVICE TOOLS DESCRIPTION Tool (Number and Name) Illustration Application Fuel Pressure Gauge (09353-24100) Measuring the fuel line pressure Fuel Pressure Gauge Adapter (09353-38000) Connection between the delivery pipe and the fuel feed line Fuel Pressure Gauge Connector (09353-24000) Connection between the Fuel Pressure Gauge (09353-24100) and the Fuel Pressure Gauge Adapter (09353-38000) Heated Oxygen Sensor Socket Wrench (09392-1Y100) Removal and installation of the heated oxygen sensor Fuel Pump Plate Cover Wrench (09310-2B200) Removal or installation of fuel pump plate cover

Scheme 36

Scheme 36: Special Service Tools
Scheme 36: Special Service Tools

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39
