Restraints - General Information: Wiring Kia Carnival III

Wiring Precautions

SRS wiring can be identified by special yellow outer covering (except the SRS circuits under the front seats).

Observe the instructions described in this Service Information.

1. Never attempt to modify, splice, or repair SRS wiring.

If there is an open or damage in SRS wiring, replace the harness.

Scheme 27

Scheme 28

1. Be sure to install the harness wires so that they are not pinched, or interfere with other parts.
2. Make sure all SRS ground locations are clean, and grounds are securely fastened for optimum metal-to-metal contact. Poor grounding can cause intermittent problems that are difficult to diagnose.

Scheme 29

1. When using electrical test equipment, insert the probe of the tester into the wire side of the connector. Do not insert the probe of the tester into the terminal side of the connector, and do not tamper with the connector.
2. Use a u-shaped probe. Do not insert the probe forcibly.
3. Use specified service connectors for troubleshooting.

Using improper tools could cause an error in inspection due to poor metal contact.

Scheme 30
