RELAYS
| Component | Location |
|---|---|
| Hazard Flasher | In fuse panel. |
RELAYS LOCATION
CONTROL UNITS/TIMERS
| Component | Location |
|---|---|
| Constant Voltage Regulator (CVR) | In coolant temperature gauge housing. |
| Cruise Control Regulator | Under instrument panel near headlight switch. |
| Electronic Ignition Control Unit | Near battery. |
| ECM Microprocessor (6-Cyl.) | Left side inner fender panel. (Scheme 1) |
| Windshield Wiper Governor | Attached to bracket near wiper control switch. (Scheme 2) |
CONTROL UNITS/TIMERS LOCATION
SENDING UNITS/SENSOR SWITCHES
| Component | Location |
|---|---|
| Air Temperature Sensor | In air cleaner. (Scheme 3) |
| Coolant Temperature Switch | On side of intake manifold. (Scheme 1)& (Scheme 4). |
| Cruise Control Speed Sensor | Between upper and lower speedometer cables. |
| Fuel Gauge Sending Unit | On top rear of fuel tank. |
| Intake Manifold Heater Switch | On side of intake manifold. (Scheme 4) |
| Knock Sensor (6-Cyl.) | On top of intake manifold. (Scheme 1)& (Scheme 4). |
| Oxygen Sensor | In exhaust manifold. (Scheme 1) |
| Thermal Electric Switch | In air cleaner. (Scheme 1)& (Scheme 3). |
| Thermal Vacuum Switch | In air cleaner. (Scheme 3) |
| Vacuum Switch (6-Cyl.) | On right side on engine block. (Scheme 1) |
| Wide Open Throttle (WOT) Switch | On base of throttle body. (Scheme 1) |
SENDING UNITS/SENSOR SWITCHES LOCATION
MOTORS
| Component | Location |
|---|---|
| A/C-Heater Blower Motor | Under dash. |
| Vacuum Motor | On air cleaner inlet. (Scheme 3) |
| Windshield Washer Motor | In water reservoir. |
| Windshield Wiper Motor | On adapter plate under dash panel. |
MOTORS LOCATION
SWITCHES
| Component | Location |
|---|---|
| Back-Up Light Switch | On left side of transmission case. |
| Brake/Stop Light Switch | On pedal bracket. (Scheme 5) |
| 4WD Indicator Switch | On side of transfer case. |
SWITCHES LOCATION
COMPONENT LOCATION GRAPHICS
Note. Figures may show multiple component locations. Refer to appropriate table for proper figure references.
